Toyota Tercel
1994-09 → 1999-07 · chassis EL50,53 · catalogue 141350 · General
Discontinued model
Data version 2000-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83420 — Gage Assy, Water Temperature Sender | ||||
| 83420-16020 |
Gage Assy, Water Temperature Sender
1994-09 → 1996-08
ended
|
EL53;EL50 GCC;EL50 RHD | — | |
| 83420-16020 |
Gage Assy, Water Temperature Sender
1996-08 → —
|
EL50 | — | |
| 83420-20040 |
Gage Assy, Water Temperature Sender
1994-09 → 1996-08
ended
|
EL50 LHD GEN | — | |
| 83420-20040 |
Gage Assy, Water Temperature Sender
1996-08 → 1997-05
ended
|
EL53 | — | |
| 83530 — Switch Assy, Oil Pressure (FOR ENGINE) | ||||
| 83530-14060 |
Switch Assy, Oil Pressure (FOR ENGINE)
1994-09 → 1994-11
ended
|
EL5# | — | |
| 83530-28020 |
Switch Assy, Oil Pressure (FOR ENGINE)
1998-03 → —
|
EL5# | — | |
| 83530-30090 |
Switch Assy, Oil Pressure (FOR ENGINE)
1994-11 → 1998-03
ended
|
EL5# | — | |
| 84210 — Switch Assy, Back-up Lamp | ||||
| 84210-12040 |
Switch Assy, Back-up Lamp
1994-09 → —
|
EL5# 5F | — | |
| 84540 — Switch Assy, Neutral Start | ||||
| 84540-16050 |
Switch Assy, Neutral Start
1994-09 → —
|
EL5# ATM | — | |
| 89427 — Switch, Temperature Detect | ||||
| 89427-12090 |
Switch, Temperature Detect
1995-08 → 1997-05
ended
|
EL50 5F GCC | — | |
| 89427-12090 |
Switch, Temperature Detect
1997-05 → —
|
EL50 LHD 5F | — | |
| 89428 — Switch, Temperature Detect, NO.2 | ||||
| 89428-12160 |
Switch, Temperature Detect, NO.2
1994-09 → —
|
EL5# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
