Toyota Tercel
1994-09 → 1999-07 · chassis EL50,53 · catalogue 141350 · General
Discontinued model
Data version 2000-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 87103 — Motor Sub-assy, Heater Blower, W/Fan | ||||
| 87103-16030 |
Motor Sub-assy, Heater Blower, W/Fan
1994-09 → —
|
EL50 RHD | — | |
| 87103-16040 |
Motor Sub-assy, Heater Blower, W/Fan
1994-09 → —
|
EL5# LHD | — | |
| 87130 — Blower Assy, Heater, Front | ||||
| 87130-16180 |
Blower Assy, Heater, Front
1994-09 → —
|
EL50 RHD | — | |
| 87130-16190 |
Blower Assy, Heater, Front
1994-09 → —
|
EL5# LHD | — | |
| 87150 — Radiator Assy, Heater | ||||
| 87150-16480 |
Radiator Assy, Heater
1994-09 → 1996-08
ended
|
EL50 RHD | — | |
| 87150-16481 |
Radiator Assy, Heater
1996-08 → —
|
EL50 RHD | — | |
| 87150-16560 |
Radiator Assy, Heater
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 87150-16561 |
Radiator Assy, Heater
1996-08 → —
|
EL5# LHD | — | |
| 88910 — Ventilator Assy, Boost | ||||
| 88910-16070 |
Ventilator Assy, Boost
1994-09 → —
|
EL50 RHD | — | |
| 88910-16080 |
Ventilator Assy, Boost
1994-09 → —
|
EL5# LHD | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
