Toyota Tercel
1994-09 → 1999-07 · chassis EL50,53 · catalogue 141350 · General
Discontinued model
Data version 2000-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 28800 — Battery | ||||
| 28800-13060 note |
Battery
1994-09 → 1996-03
ended
|
2E,5EFE EL5# | — | |
| 28800-13060 note |
Battery
1996-08 → —
|
2E,5EFE EL5# | — | |
| 28800-24030 note |
Battery
1994-09 → —
|
2E,5EFE EL5# | — | |
| 28800-33050 note |
Battery
1995-08 → 1997-12
ended
|
2E EL50 5F GCC | — | |
| 28800-33090 note |
Battery
1994-09 → —
|
2E,5EFE EL5# | — | |
| 28800A — Terminal, Battery Positive | ||||
| 90982-05034 |
Terminal, Battery Positive
1994-09 → —
|
2E,5EFE EL5# | — | |
| 90982-05035 note |
Terminal, Battery Positive
1994-09 → —
|
2E,5EFE EL5# | — | |
| 28800D — Cover, Connector(FOR BATTERY TERMINAL) | ||||
| 82821-12290 |
Cover, Connector(FOR BATTERY TERMINAL)
1994-09 → —
|
2E,5EFE EL5# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
