Toyota Vios
2019-11 → present · chassis NSP15# · catalogue 14C310 · General
Supported model
Data version 2019-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 89413D — Ring, O(FOR TRANSMISSION REVOLUTION SENSOR) | ||||
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2019-11 → 2024-05
ended
|
NSP151 CVT | — | |
| 90301-11008 |
Ring, O(FOR TRANSMISSION REVOLUTION SENSOR)
2019-11 → —
|
NSP150 CVT | — | |
| 89413M — Sensor, Transmission Revolution, (NOUT) | ||||
| 89413-12020 |
Sensor, Transmission Revolution, (NOUT)
2019-11 → 2024-05
ended
|
NSP151 CVT | — | |
| 89413-28011 |
Sensor, Transmission Revolution, (NOUT)
2019-11 → —
|
NSP150 CVT | — | |
| 89413N — Sensor, Transmission Revolution, (NT) | ||||
| 89413-12020 |
Sensor, Transmission Revolution, (NT)
2019-11 → —
|
NSP150 CVT | — | |
| 89413-50020 |
Sensor, Transmission Revolution, (NT)
2019-11 → 2024-05
ended
|
NSP151 CVT | — | |
| 89413P — Sensor, Transmission Revolution, (NIN) | ||||
| 89413-60021 |
Sensor, Transmission Revolution, (NIN)
2019-11 → 2024-05
ended
|
NSP151 CVT | — | |
| 89413-60021 |
Sensor, Transmission Revolution, (NIN)
2019-11 → —
|
NSP150 CVT | — | |
| 89637K — Sensor, Oil Pressure | ||||
| 89637-63010 |
Sensor, Oil Pressure
2019-11 → 2024-05
ended
|
NSP151 CVT | — | |
| 89637-63010 |
Sensor, Oil Pressure
2019-11 → —
|
NSP150 CVT | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
