Toyota Vios/Yaris

2021-01 → present · chassis NSP151 · catalogue 14H310 · General

Supported model Data version 2020-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Radiator Grille

6 part groups · 2 illustrations

Illustrations

Figure 537577B 537577B 2021-01 → — Figure 537578B 537578B 2021-01 → —

Part groups

PNCDescription
52161R Piece, Front Bumper
53101 Grille Sub-assy, Radiator
53119B Protector, Radiator Grille
53123B Moulding, Radiator Grille Side, RH
53124C Moulding, Radiator Grille, Upper LH
53384D Cushion, Hood, Center
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
