Toyota Corolla Sed/LB
1983-05 → 1988-07 · chassis EE80,AE8#,CE80 · catalogue 151210 · General
Discontinued model
Data version 1989-05
Exhaust Pipe
31 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 17400 | Converter Assy, W/Catalyst |
| 17410 | Pipe Assy, Exhaust, Front |
| 17410A | Nut, Exhaust Pipe Set Stud Bolt |
| 17410B | Gasket, Exhaust Pipe |
| 17410C | Bracket, Exhaust Pipe Front (FOR FRONT) |
| 17410F | Bolt OR Ring, Exhaust Pipe Front (FOR FRONT) |
| 17410H | Bracket, Exhaust Pipe Front (FOR CENTER) |
| 17410T | Bolt OR Ring, Exhaust Pipe Front (FOR CENTER) |
| 17410V | Bracket, Exhaust Pipe Front (FOR REAR) |
| 17410Y | Bolt OR Ring, Exhaust Pipe Front (FOR REAR) |
| 17419 | Pipe, Converter Air Inlet |
| 17419A | Clamp, NO.1(FOR CONVERTER AIR INLET PIPE) |
| 17419B | Bolt, U(FOR CONVERTER AIR INLET PIPE) |
| 17420 | Pipe Assy, Exhaust, Center |
| 17420A | Bracket, Exhaust Pipe Center, Front |
| 17420D | Bolt OR Ring, Exhaust Pipe Center, Front |
| 17420S | Bracket, Exhaust Pipe Center, Rear |
| 17420V | Bolt OR Ring, Exhaust Pipe Center, Rear |
| 17420X | Gasket, Exhaust Pipe, Center |
| 17430 | Pipe Assy, Exhaust, Tail |
| 17430A | Bracket, Exhaust Tailpipe(FOR FRONT) |
| 17430D | Bolt OR Ring, Exhaust Tailpipe (FOR FRONT) |
| 17430F | Bracket, Exhaust Tailpipe(FOR CENTER) |
| 17430S | Bracket, Exhaust Tailpipe (FOR REAR) |
| 17430V | Bolt OR Ring, Exhaust Tailpipe (FOR REAR) |
| 17448 | Baffle, Tailpipe |
| 17451 | Gasket, Exhaust Pipe |
| 17502B | Bracket Sub-assy, Catalytic Converter, Front |
| 17503 | Bracket Sub-assy, Catalytic Converter, Rear |
| 17595 | Protector, Exhaust Pipe, Lower NO.3 |
| 18435 | Protector, Catalytic Converter |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
