Toyota E'z

2011-06 → 2016-12 · chassis ZGR2# · catalogue 158310 · General

Supported model Data version 2016-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Quarter Window

8 part groups · 1 illustrations

Illustrations

Figure 613421B 613421B 2011-06 → —

Part groups

PNCDescription
62110A Window Assy, Front Side Fix, RH
62120B Window Assy, Front Side Fix, LH
62710A Window Assy, Quarter, RH
62720A Window Assy, Quarter, LH
62785E Spacer, Quarter Window Glass, RH
62786C Spacer, Quarter Window Glass, LH
75641E Moulding, Quarter Window, RH
75642E Moulding, Quarter Window, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
