Toyota Wish

2003-12 → 2009-10 · chassis ANE1#,ZNE10 · catalogue 163210 · General

Supported model Data version 2010-01

Side Moulding

36 part groups · 2 illustrations

PNC	Description
53825F	Protector, Front Fender, Upper RH
53826D	Protector, Front Fender, Upper LH
53851G	Pad, Front Wheel Opening Extension, RH
53852D	Pad, Front Wheel Opening Extension, LH
61783J	Pad, Rear Wheel Opening Extension, NO.2
61784E	Pad, Rear Wheel Opening Extension, NO.2
75039	Clip Sub-assy, Outside Moulding
75085A	Moulding Sub-assy, Front Fender Wheel Opening, RH
75086	Moulding Sub-assy, Front Fender Wheel Opening, LH
75392A	Retainer, Outside Moulding, NO.1
75398A	Clip, Outside Moulding, NO.5
75495	Clip, Outside Moulding, NO.4
75498B	Seal, Outside Moulding, NO.2
75499A	Seal, Outside Moulding, NO.3
75551E	Moulding, Roof Drip Side Finish, RH
75552E	Moulding, Roof Drip Side Finish, LH
75561	Clip, Roof Drip Side Finish Moulding, NO.1
75586D	Retainer, Quarter Garnish Front Moulding, NO.2
75653A	Moulding, Quarter, Outside Rear RH
75654A	Moulding, Quarter, Outside Rear LH
75707	Moulding Sub-assy, Rear Door Window Frame, RH
75708	Moulding Sub-assy, Rear Door Window Frame, LH
75711B	Moulding, Front Door Belt, RH
75712B	Moulding, Front Door Belt, LH
75721A	Moulding, Rear Door Belt, RH
75722A	Moulding, Rear Door Belt, LH
75731A	Moulding, Front Door, Outside RH
75732A	Moulding, Front Door, Outside LH
75741	Moulding, Rear Door, Outside RH
75742	Moulding, Rear Door, Outside LH
75851	Moulding, Rocker Panel, RH
75852	Moulding, Rocker Panel, LH
75871	Moulding, Front Fender Wheel Opening, RH
75872	Moulding, Front Fender Wheel Opening, LH
76069	Cover Sub-assy, Rear Door Mudguard, RH
76079	Cover Sub-assy, Rear Door Mudguard, LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
