Toyota Corolla (TUP)
2019-01 → present · chassis MZEA11,ZRE21#, ZWE21# · catalogue 164230 · General
Supported model
Data version 2022-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 68750 — Hinge Assy, Rear Door, Upper RH | ||||
| 68750-0H010 |
Hinge Assy, Rear Door, Upper RH
2019-01 → 2023-01
ended
|
ZRE210 US);ZRE210 N LHD +11 | — | |
| 68750-0H010 |
Hinge Assy, Rear Door, Upper RH
2019-01 → —
|
ZWE211,213;ZRE211 D 1,ZRE211 RHD;MZEA11 +22 | — | |
| 68750-0H010 |
Hinge Assy, Rear Door, Upper RH
2019-01 → 2020-12
ended
|
ZRE210 G EUR;ZRE210 RHD +1 | — | |
| 68750-0H010 |
Hinge Assy, Rear Door, Upper RH
2023-01 → —
|
ZWE219;MZEA11 210 TUR;ZRE210 LHD +13 | — | |
| 68760 — Hinge Assy, Rear Door, Upper LH | ||||
| 68760-0H010 |
Hinge Assy, Rear Door, Upper LH
2019-01 → 2020-12
ended
|
ZRE210 G EUR;ZRE210 RHD +1 | — | |
| 68760-0H010 |
Hinge Assy, Rear Door, Upper LH
2019-01 → 2023-01
ended
|
ZRE210 US);ZRE210 N LHD +11 | — | |
| 68760-0H010 |
Hinge Assy, Rear Door, Upper LH
2019-01 → —
|
ZWE211,213;ZRE211 D 1,ZRE211 RHD;MZEA11 +22 | — | |
| 68760-0H010 |
Hinge Assy, Rear Door, Upper LH
2023-01 → —
|
ZWE219;MZEA11 210 TUR;ZRE210 LHD +13 | — | |
| 68770 — Hinge Assy, Rear Door, Lower RH | ||||
| 68770-02080 |
Hinge Assy, Rear Door, Lower RH
2019-01 → 2020-12
ended
|
ZRE210 G EUR;ZRE210 RHD +1 | — | |
| 68770-02080 |
Hinge Assy, Rear Door, Lower RH
2019-01 → 2023-01
ended
|
ZRE210 US);ZRE210 N LHD +11 | — | |
| 68770-02080 |
Hinge Assy, Rear Door, Lower RH
2019-01 → —
|
ZWE211,213;ZRE211 D 1,ZRE211 RHD;MZEA11 +22 | — | |
| 68770-02080 |
Hinge Assy, Rear Door, Lower RH
2023-01 → —
|
ZWE219;MZEA11 210 TUR;ZRE210 LHD +13 | — | |
| 68780 — Hinge Assy, Rear Door, Lower LH | ||||
| 68780-02080 |
Hinge Assy, Rear Door, Lower LH
2019-01 → 2020-12
ended
|
ZRE210 G EUR;ZRE210 RHD +1 | — | |
| 68780-02080 |
Hinge Assy, Rear Door, Lower LH
2019-01 → 2023-01
ended
|
ZRE210 US);ZRE210 N LHD +11 | — | |
| 68780-02080 |
Hinge Assy, Rear Door, Lower LH
2019-01 → —
|
ZWE211,213;ZRE211 D 1,ZRE211 RHD;MZEA11 +22 | — | |
| 68780-02080 |
Hinge Assy, Rear Door, Lower LH
2023-01 → —
|
ZWE219;MZEA11 210 TUR;ZRE210 LHD +13 | — | |
| 69830A — Regulator Assy, Rear Door Window, RH | ||||
| 69830-02730 |
Regulator Assy, Rear Door Window, RH
2019-01 → 2020-12
ended
|
ZRE210 G EUR;ZRE210 RHD +1 | — | |
| 69830-02730 |
Regulator Assy, Rear Door Window, RH
2019-01 → 2022-04
ended
|
ZRE210 G RUS;ZRE210 RHD +3 | — | |
| 69830-02732 |
Regulator Assy, Rear Door Window, RH
2022-05 → 2022-06
ended
|
MZEA11,ZRE21#,ZWE21# | — | |
| 69830-02733 |
Regulator Assy, Rear Door Window, RH
2022-06 → 2023-01
ended
|
ZRE210 US);ZRE210 N LHD +11 | — | |
| 69830-02733 |
Regulator Assy, Rear Door Window, RH
2022-06 → —
|
ZWE211,213;ZRE211 .RUS;ZRE210 CVT RHD;MZEA11 +18 | — | |
| 69830-02731 |
Regulator Assy, Rear Door Window, RH
2023-01 → —
|
ZWE219;MZEA11 TUR;MZEA11 LHD (D,N) +1 | — | |
| 69830-02733 |
Regulator Assy, Rear Door Window, RH
2023-01 → —
|
ZRE210 .LHD N CVT +10 | — | |
| 69840A — Regulator Assy, Rear Door Window, LH | ||||
| 69840-02740 |
Regulator Assy, Rear Door Window, LH
2019-01 → 2020-12
ended
|
ZRE210 G EUR;ZRE210 RHD +1 | — | |
| 69840-02740 |
Regulator Assy, Rear Door Window, LH
2019-01 → 2022-04
ended
|
ZRE210 G RUS;ZRE210 RHD +3 | — | |
| 69840-02742 |
Regulator Assy, Rear Door Window, LH
2022-05 → 2022-06
ended
|
MZEA11,ZRE21#,ZWE21# | — | |
| 69840-02743 |
Regulator Assy, Rear Door Window, LH
2022-06 → 2023-01
ended
|
ZRE210 US);ZRE210 N LHD +11 | — | |
| 69840-02743 |
Regulator Assy, Rear Door Window, LH
2022-06 → —
|
ZWE211,213;ZRE211 .RUS;ZRE210 CVT RHD;MZEA11 +18 | — | |
| 69840-02741 |
Regulator Assy, Rear Door Window, LH
2023-01 → —
|
ZWE219;MZEA11 TUR;MZEA11 LHD (D,N) +1 | — | |
| 69840-02743 |
Regulator Assy, Rear Door Window, LH
2023-01 → —
|
ZRE210 .LHD N CVT +10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
