Toyota Corolla
2013-06 → present · chassis NDE180,NRE180,ZRE18#,ZRE21#,ZWE219 · catalogue 164320 · General
Supported model
Data version 2019-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15104 — Strainer Sub-assy, Oil | ||||
| 15104-47040 |
Strainer Sub-assy, Oil
2014-01 → 2017-01
ended
|
1NRFE NRE180 SAP | — | |
| 15104-47040 |
Strainer Sub-assy, Oil
2016-06 → 2018-08
ended
|
1NRFE NRE180 TUP | — | |
| 15104-47040 |
Strainer Sub-assy, Oil
2016-06 → —
|
1NRFE NRE180 SAP | — | |
| 15104A — Ring, O(FOR OIL STRAINER) | ||||
| 90301-22018 |
Ring, O(FOR OIL STRAINER)
2014-01 → 2017-01
ended
|
1NRFE NRE180 SAP | — | |
| 90301-22018 |
Ring, O(FOR OIL STRAINER)
2016-06 → 2018-08
ended
|
1NRFE NRE180 TUP | — | |
| 90301-22018 |
Ring, O(FOR OIL STRAINER)
2016-06 → —
|
1NRFE NRE180 SAP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
