Toyota Corolla
2013-06 → present · chassis NDE180,NRE180,ZRE18#,ZRE21#,ZWE219 · catalogue 164320 · General
Supported model
Data version 2019-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11176 — Seat, Injection Nozzle | ||||
| 11176-33010 |
Seat, Injection Nozzle
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 11176-33010 |
Seat, Injection Nozzle
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 11176-33010 |
Seat, Injection Nozzle
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 11176-33010 |
Seat, Injection Nozzle
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23670 — Injector Assy | ||||
| 23670-09390 |
Injector Assy
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23670-09390 |
Injector Assy
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23670-09390 |
Injector Assy
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23670-09390 |
Injector Assy
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23695 — Clamp, Nozzle Holder, NO.1 | ||||
| 23695-33020 |
Clamp, Nozzle Holder, NO.1
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23695-33020 |
Clamp, Nozzle Holder, NO.1
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23695-33020 |
Clamp, Nozzle Holder, NO.1
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23695-33020 |
Clamp, Nozzle Holder, NO.1
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23699A — Seat, Nozzle Holder Clamp | ||||
| 23699-33020 |
Seat, Nozzle Holder Clamp
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23699-33020 |
Seat, Nozzle Holder Clamp
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23699-33020 |
Seat, Nozzle Holder Clamp
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23699-33020 |
Seat, Nozzle Holder Clamp
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23760 — Pipe Assy, Nozzle Leakage | ||||
| 23760-0W010 |
Pipe Assy, Nozzle Leakage
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23760-0W010 |
Pipe Assy, Nozzle Leakage
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23760-0W010 |
Pipe Assy, Nozzle Leakage
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23760-0W010 |
Pipe Assy, Nozzle Leakage
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23770A — Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET) | ||||
| 23841-33030 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23841-33030 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23841-33040 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23841-33040 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23841-33050 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2013-06 → 2016-05
ended
|
1NDTV NDE180 TUP | — | |
| 23841-33050 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2013-06 → 2017-01
ended
|
1NDTV NDE180 SAP | — | |
| 23841-33030 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23841-33030 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23841-33040 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23841-33040 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2016-06 → —
|
1NDTV NDE180 SAP | — | |
| 23841-33050 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2016-06 → 2019-01
ended
|
1NDTV NDE180 TUP | — | |
| 23841-33050 note |
Clamp OR Clip(FOR NOZZLE LEAKAGE PIPE SET)
2016-06 → —
|
1NDTV NDE180 SAP | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
