Toyota Auris/Corolla HB(Jpp

2018-06 → present · chassis MZEA12,NRE210,ZWE21# · catalogue 165230 · General

Supported model Data version 2022-09
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Panel & Glass

16 part groups · 2 illustrations

Illustrations

Figure 679932F 679932F 2018-06 → — Figure 679933 679933 2018-06 → —

Part groups

PNCDescription
62785F Spacer, Back Door Glass
64338C Hook, Package Tray Trim Garnish, RH
64338D Hook, Package Tray Trim Garnish, LH
64780A Panel Assy, Back Door Trim
64780B Clip(FOR BACK DOOR TRIM PANEL)
64818C Spacer, Back Window Glass, NO.1
64819 Spacer, Back Window Glass, NO.2
64827D Clip, Back Window Glass
67005 Panel Sub-assy, Back Door
67005B Cushion(FOR BACK DOOR PANEL)
67766 Cover, Back Door Service Hole, NO.2
67881A Weatherstrip, Back Door
68131 Glass, Back Door
69477 Cushion, Back Door Upper Stopper
75575D Moulding, Back Window, Lower
76827B Retainer, Back Door Garnish, NO.2
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
