Toyota Corolla/Auris (JPP)
2012-08 → 2018-05 · chassis NRE180,ZRE18#,ZWE186 · catalogue 165320 · General
Supported model
Data version 2018-11
Instrument Panel & Glove Compartment
65 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 55045 | Panel Sub-assy, Instrument Panel Finish, Lower |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55312A | Clip, Instrument Panel |
| 55317A | Panel, Instrument Side, RH |
| 55318C | Panel, Instrument Side, LH |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55343B | Brace, Instrument Panel TO Cowl, Center |
| 55345A | Clip, Instrument Panel, NO.1 |
| 55346A | Clip, Instrument Panel, NO.2 |
| 55349A | Cushion, Instrument Panel |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55355E | Cushion, Instrument Panel |
| 55356C | Cushion, Instrument Panel, NO.2 |
| 55376 | Bracket, Instrument Panel Mounting, NO.1 |
| 55377A | Bracket, Instrument Panel Mounting, NO.2 |
| 55388B | Bracket, Console Mounting, RH |
| 55389 | Bracket, Console Mounting, LH |
| 55402C | Pad Sub-assy, Instrument Panel, Lower RH |
| 55403C | Pad Sub-assy, Instrument Panel, Lower LH |
| 55403F | Panel Sub-assy, Instrument Panel Finish |
| 55404E | Panel Sub-assy, Instrument Cluster Finish, Upr |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55406D | Clip(FOR PANEL, INSTRUMENT CLUSTER FINISH) |
| 55410C | Panel Assy, Instrument Cluster Finish |
| 55412A | Clip, Panel, Instrument Cluster Finish, End |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55412E | Clip, Panel, Instrument Cluster Finish, End |
| 55412G | Clip(FOR INSTRUMENT CENTER CLUSTER FINISH PANEL) |
| 55416C | Retainer, Instrument Cluster Finish Panel |
| 55422A | Panel, Instrument Cluster Finish, Lower |
| 55433B | Panel, Instrument Panel Finish, Lower NO.2 |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55434D | Clip, Instrument Panel Finish, Lower Center |
| 55435B | Cluster, Meter Hood, NO.1 |
| 55440D | Box Assy, Instrument Panel |
| 55446A | Base, Switch Hole, NO.1 |
| 55447C | Base, Switch Hole, NO.2 |
| 55450B | Box Assy, Coin |
| 55455B | Coin Box |
| 55458E | Clip(FOR INSTRUMENT LOWER COVER) |
| 55468 | Cover, Heater Switch Hole |
| 55470 | Garnish Assy, Instrument Cluster Finish Panel |
| 55521C | Cover, Stereo Opening |
| 55521F | Cover, Stereo Opening, NO.2 |
| 55539 | Cover, Spare Switch Hole |
| 55550 | Door Assy, Glove Compartment |
| 55557A | Cushion, Glove Compartment Door Check |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55607 | Cover Sub-assy, Instrument Panel Under, NO.2 |
| 55629A | Cushion, Instrument Panel Under Tray |
| 55670A | Register Assy, Instrument Panel, Center |
| 55680A | Register Assy, Instrument Panel, NO.4 |
| 55961 | Nozzle, Side Defroster, NO.1 |
| 55962 | Nozzle, Side Defroster, NO.2 |
| 55981 | Garnish, Defroster Nozzle, NO.1 |
| 58816C | Insert, Console Box, Front NO.1 |
| 58817B | Insert, Console Box, Front NO.2 |
| 58959E | Cushion, Console Compartment Door |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
