Toyota Auris (UKP)
2007-06 → 2012-10 · chassis ADE150,NRE150,ZRE15#,ZZE150 · catalogue 166310 · General
Supported model
Data version 2013-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 31210 — Cover Assy, Clutch | ||||
| 31210-02200 |
Cover Assy, Clutch
2007-06 → 2008-11
ended
|
ZZE150 | — | |
| 31210-02210 note |
Cover Assy, Clutch
2007-06 → 2009-02
ended
|
ZRE151 5F | — | |
| 31210-02220 note |
Cover Assy, Clutch
2007-06 → 2009-02
ended
|
ZRE152 | — | |
| 31210-12291 note |
Cover Assy, Clutch
2007-06 → 2009-02
ended
|
ZRE152 | — | |
| 31210-52052 note |
Cover Assy, Clutch
2007-06 → 2009-02
ended
|
ZRE151 5F | — | |
| 31210-05120 |
Cover Assy, Clutch
2009-02 → 2010-01
ended
|
ZRE151 6F (RS,RT) | — | |
| 31210-05130 |
Cover Assy, Clutch
2009-02 → 2010-01
ended
|
ZRE152 | — | |
| 31210-12360 |
Cover Assy, Clutch
2009-02 → 2010-01
ended
|
ZRE151 6FS | — | |
| 31210-52130 |
Cover Assy, Clutch
2008-11 → 2010-01
ended
|
NRE150 | — | |
| 31210-05120 |
Cover Assy, Clutch
2009-12 → 2012-10
ended
|
ZRE151 SOL,TERRA | — | |
| 31210-52130 |
Cover Assy, Clutch
2009-12 → 2012-10
ended
|
NRE150 TERRA | — | |
| 31250 — Disc Assy, Clutch | ||||
| 31250-02140 |
Disc Assy, Clutch
2007-06 → 2008-11
ended
|
ZZE150 | — | |
| 31250-02160 note |
Disc Assy, Clutch
2007-06 → 2008-02
ended
|
ZRE15# 5F,6F | — | |
| 31250-02161 note |
Disc Assy, Clutch
2008-03 → 2009-02
ended
|
ZRE15# 5F,6F | — | |
| 31250-12510 note |
Disc Assy, Clutch
2007-06 → 2009-02
ended
|
ZRE15# 5F,6F | — | |
| 31250-05140 |
Disc Assy, Clutch
2009-02 → 2010-01
ended
|
ZRE15# 6F (RS,RT,RX) | — | |
| 31250-12480 |
Disc Assy, Clutch
2009-02 → 2009-12
ended
|
ZRE151 6FS | — | |
| 31250-52120 |
Disc Assy, Clutch
2008-11 → 2010-01
ended
|
NRE150 | — | |
| 31250-05140 |
Disc Assy, Clutch
2009-12 → 2012-10
ended
|
ZRE151 SOL,TERRA | — | |
| 31250-52120 |
Disc Assy, Clutch
2009-12 → 2010-09
ended
|
NRE150 TERRA | — | |
| 31250-52210 |
Disc Assy, Clutch
2010-10 → 2012-10
ended
|
NRE150 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
