Toyota Auris (UKP)

2007-06 → 2012-10 · chassis ADE150,NRE150,ZRE15#,ZZE150 · catalogue 166310 · General

Supported model Data version 2013-04
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Mudguard & Spoiler

12 part groups · 2 illustrations

Illustrations

Figure 760608D 760608D 2007-06 → — Figure 760609E 760609E 2007-06 → —

Part groups

PNCDescription
52161L Piece, Front Spoiler
76851B Spoiler, Front, RH
76852B Spoiler, Front, LH
76869C Grommet, Screw, NO.1
76869D Screw, NO.2
76871 Spoiler, Rear
76873 Protector, Rear Spoiler, NO.2
76874 Protector, Rear Spoiler, NO.3
76875 Protector, Rear Spoiler, NO.4
76876A Protector, Rear Spoiler, NO.10
76881 Protector, Rear Spoiler Side, NO.1 RH
76882 Protector, Rear Spoiler Side, NO.1 LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
