Toyota Auris (UKP)
2012-10 → 2018-11 · chassis ZRE181 · catalogue 166320 · General
Supported model
Data version 2019-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 53181E — Cover, Headlamp, RH | ||||
| 53181-02090 |
Cover, Headlamp, RH
2015-05 → —
|
ZRE181 | — | |
| 53182E — Cover, Headlamp, LH | ||||
| 53182-02090 |
Cover, Headlamp, LH
2015-05 → —
|
ZRE181 | — | |
| 53271A — Bracket, Headlamp Mounting | ||||
| 53271-44010 |
Bracket, Headlamp Mounting
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 53271-44010 |
Bracket, Headlamp Mounting
2015-05 → —
|
ZRE181 | — | |
| 81110B — Bulb(FOR HEADLAMP, NO.1) | ||||
| 90981-13089 note |
Bulb(FOR HEADLAMP, NO.1)
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 90981-13089 note |
Bulb(FOR HEADLAMP, NO.1)
2015-05 → —
|
ZRE181 | — | |
| 81135 — Unit Assy, Headlamp, RH | ||||
| 81130-02E20 |
Unit Assy, Headlamp, RH
2012-10 → 2013-03
ended
|
ZRE181 | — | |
| 81130-02J60 |
Unit Assy, Headlamp, RH
2013-03 → 2015-04
ended
|
ZRE181 | — | |
| 81130-02J61 |
Unit Assy, Headlamp, RH
2015-04 → 2015-05
ended
|
ZRE181 | — | |
| 81130-02K30 |
Unit Assy, Headlamp, RH
2015-05 → —
|
ZRE181 | — | |
| 81139 — Cover, Headlamp Socket | ||||
| 81139-02E20 |
Cover, Headlamp Socket
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 81139-02E20 |
Cover, Headlamp Socket
2015-05 → —
|
ZRE181 | — | |
| 81175 — Unit Assy, Headlamp, LH | ||||
| 81170-02E20 |
Unit Assy, Headlamp, LH
2012-10 → 2013-03
ended
|
ZRE181 | — | |
| 81170-02J60 |
Unit Assy, Headlamp, LH
2013-03 → 2015-04
ended
|
ZRE181 | — | |
| 81170-02J61 |
Unit Assy, Headlamp, LH
2015-04 → 2015-05
ended
|
ZRE181 | — | |
| 81170-02K30 |
Unit Assy, Headlamp, LH
2015-05 → —
|
ZRE181 | — | |
| 81193 — Retainer, Headlamp Protector, Upper RH | ||||
| 81193-12180 |
Retainer, Headlamp Protector, Upper RH
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 81193-12180 |
Retainer, Headlamp Protector, Upper RH
2015-05 → —
|
ZRE181 | — | |
| 81194 — Retainer, Headlamp Protector, Upper LH | ||||
| 81194-12180 |
Retainer, Headlamp Protector, Upper LH
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 81194-12180 |
Retainer, Headlamp Protector, Upper LH
2015-05 → —
|
ZRE181 | — | |
| 81195A — Retainer, Headlamp Protector, Lower RH | ||||
| 81195-12240 |
Retainer, Headlamp Protector, Lower RH
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 81195-12240 |
Retainer, Headlamp Protector, Lower RH
2015-05 → —
|
ZRE181 | — | |
| 81196A — Retainer, Headlamp Protector, Lower LH | ||||
| 81196-12240 |
Retainer, Headlamp Protector, Lower LH
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 81196-12240 |
Retainer, Headlamp Protector, Lower LH
2015-05 → —
|
ZRE181 | — | |
| 81510C — Bulb (FOR FRONT TURN SIGNAL LAMP) | ||||
| 90981-WF003 note |
Bulb (FOR FRONT TURN SIGNAL LAMP)
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 90981-15011 note |
Bulb (FOR FRONT TURN SIGNAL LAMP)
2015-05 → —
|
ZRE181 | — | |
| 81515B — Socket, Front Turn Signal Lamp | ||||
| 90069-81052 |
Socket, Front Turn Signal Lamp
2012-10 → 2015-05
ended
|
ZRE181 | — | |
| 90069-81116 |
Socket, Front Turn Signal Lamp
2015-05 → —
|
ZRE181 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
