Toyota Auris (UKP)
2012-10 → 2018-11 · chassis ZRE181 · catalogue 166320 · General
Supported model
Data version 2019-04
Armrest & Visor
19 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 74230 | Armrest Assy, Rear, RH |
| 74231 | Panel, Front Armrest Base, Upper RH |
| 74232 | Panel, Front Armrest Base, Upper LH |
| 74240 | Armrest Assy, Rear, LH |
| 74271A | Panel, Rear Door Armrest Base, Upper RH |
| 74272A | Panel, Rear Door Armrest Base, Upper LH |
| 74310 | Visor Assy, RH |
| 74320 | Visor Assy, LH |
| 74348B | Holder, Visor, RH |
| 74348C | Holder, Visor, LH |
| 74610S | Grip Assy, Assist |
| 74612 | Cover, Assist Grip |
| 74612D | Cover, Assist Grip |
| 74614C | Plate, Assist Grip Lock |
| 74620C | Grip Assy, Assist, Rear RH |
| 74630C | Grip Assy, Door Assist, RH |
| 74630E | Grip Assy, Assist, Rear LH |
| 74640C | Grip Assy, Door Assist, LH |
| 74811B | Handle, Door Pull |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
