Toyota Wish
2009-11 → 2016-06 · chassis ZGE21 · catalogue 167310 · General
Discontinued model
Data version 2016-12
Rear Seat & Seat Track
113 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 71075E | Clip(FOR REAR SEAT) |
| 71393A | Band, Rear Seat Cushion, RH |
| 71393B | Band, Rear Seat Cushion, LH |
| 71461A | Spring, Rear Seat Cushion, NO.1 |
| 71462 | Spring, Rear Seat Cushion, NO.2 |
| 71485 | Cover, Rear Seat Hinge |
| 71628G | Spacer, Rear Seat Cushion, RH |
| 71628H | Spacer, Rear Seat Cushion, LH |
| 71701B | Board Sub-assy, Rear Seatback, RH |
| 71702B | Board Sub-assy, Rear Seatback, LH |
| 71769A | Clip, Rear Seatback Board |
| 71811G | Shield, Rear Seat Cushion, RH |
| 71811H | Cover, Reclining Adjuster, RH |
| 71812E | Cover, Reclining Adjuster, LH |
| 71812F | Shield, Rear Seat Cushion, LH |
| 71843A | Cover, Rear Seat Reclining, NO.2 RH |
| 71843B | Clip, Rear Seat Reclining Cover |
| 71843D | Cover, Rear Seat Reclining, NO.2 RH |
| 71844A | Cover, Rear Seat Reclining, NO.2 LH |
| 71844C | Cover, Rear Seat Reclining, NO.2 LH |
| 71875C | Cover, Reclining Adjuster Inside, RH |
| 71875E | Cover, Reclining Adjuster Inside, RH |
| 71875J | Cover, Reclining Adjuster Inside, RH |
| 71876B | Cover, Reclining Adjuster Inside, LH |
| 71876E | Cover, Reclining Adjuster Inside, LH |
| 71876J | Cover, Reclining Adjuster Inside, LH |
| 71931A | Support, Rear Seat Headrest |
| 71931E | Support Assy, Rear NO.3 Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71970 | Headrest Assy, Rear Seat |
| 72057 | Lever Sub-assy, Rear Seat Lock Control, RH |
| 72058A | Lever Sub-assy, Rear Seat Lock Control, LH |
| 72067 | Lever Sub-assy, Rear Back Lock Control, RH |
| 72068 | Lever Sub-assy, Rear Back Lock Control, LH |
| 72137C | Cover, Seat Track Inner, RH |
| 72137D | Cover, Rear Seat Track, RH |
| 72137Q | Cover, Rear Seat Track, NO.2 |
| 72137R | Cover, Rear Seat Track, NO.3 |
| 72138A | Cover, Rear Seat Track, LH |
| 72138E | Cover, Seat Track, Inner LH |
| 72138K | Cover, Rear Seat Track, LH NO.2 |
| 72138L | Cover, Rear Seat Track, LH NO.3 |
| 72160 | Track Assy, Rear Seat, Outer RH |
| 72170 | Track Assy, Rear Seat, Outer LH |
| 72170D | Track Assy, Rear Seat, Outer LH |
| 72173 | Handle, Rear Seat Track Adjusting |
| 72220 | Track Assy, Rear NO.1 Seat, Inner LH |
| 72261B | Reinforcement, Seat Track, RH |
| 72507B | Handle Sub-assy, Reclining Release, RH |
| 72507C | Handle Sub-assy, Reclining Release, LH |
| 72525C | Handle, Reclining Adjuster Release, NO.1 RH |
| 72525D | Handle, Reclining Adjuster Release, NO.2 RH |
| 72525E | Handle, Reclining Adjuster Release, NO.3 RH |
| 72526B | Handle, Reclining Adjuster Release, NO.1 LH |
| 72526C | Handle, Reclining Adjuster Release, NO.2 LH |
| 72526E | Handle, Reclining Adjuster Release, LH |
| 72553A | Protector, Reclining Cover, RH |
| 72553C | Protector, Reclining Cover, RH |
| 72554A | Protector, Reclining Cover, LH |
| 72554B | Protector, Reclining Cover, LH |
| 72595 | Base, Reclining Remote Control, RH |
| 72596 | Base, Reclining Remote Control, LH |
| 72601B | Striker Sub-assy, Rear Seatback Lock |
| 72622C | Bush, Rear Seatback Protector Shaft |
| 72704A | Cable, Rear Seat Reclining Control |
| 72704B | Cable, Rear Seat Reclining Control, NO.2 |
| 72704C | Cable, Rear NO.2 Seat Reclining Control |
| 72704D | Cable, Rear NO.2 Seat Reclining Control |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72927 | Cover, Rear Seat Cushion Under, RH |
| 72928 | Cover, Rear Seat Cushion Under, LH |
| 73115A | Clip, Belt Comfort, NO.1 |
| 73387 | Band, RR Seat Belt Guide, NO.1 |
| 78955 | Cover, Rear Seat Under Tray RH |
| 78955A | Cover, Rear Seat Under Tray |
| 79011 | Cover Sub-assy, NO.1 Seat Cushion, RH |
| 79012 | Cover Sub-assy, NO.1 Seat Cushion, LH |
| 79013 | Cover Sub-assy, NO.1 Seatback, RH |
| 79014 | Cover Sub-assy, NO.1 Seatback, LH |
| 79031B | Cover Sub-assy, NO.3 Seat Cushion, RH |
| 79032 | Cover Sub-assy, NO.3 Seat Cushion, LH |
| 79033 | Cover Sub-assy, NO.3 Seatback, RH |
| 79034 | Cover Sub-assy, NO.3 Seatback, LH |
| 79101 | Frame Sub-assy, NO.1 Seat Cushion |
| 79105 | Leg Sub-assy, NO.1 Seat, RH |
| 79106 | Leg Sub Assy, NO.1 Seat, LH |
| 79109 | Board Sub-assy, NO.1 Seatback |
| 79109A | Clip (FOR NO.1 SEATBACK BOARD) |
| 79135A | Pad, NO.1 Seat Cushion, RH |
| 79136B | Pad, NO.1 Seat Cushion, LH |
| 79139J | Cloth, NO.1 Seat Cushion RH |
| 79139K | Cloth, NO.1 Seat Cushion LH |
| 79175E | Pad, NO.1 Seatback, RH |
| 79180A | Spring Assy, NO.1 Seatback, RH |
| 79185 | Pad, NO.1 Seatback, LH |
| 79190A | Spring Assy, NO.1 Seatback, LH |
| 79201 | Frame Sub-assy, NO.2 Seat Cushion |
| 79209 | Board Sub-assy, NO.2 Seatback |
| 79209A | Clip (FOR NO.2 SEATBACK BOARD) |
| 79303A | Frame Sub-assy, NO.3 Seatback, RH |
| 79304A | Frame Sub-assy, NO.3 Seatback, LH |
| 79305A | Leg Sub-assy, NO.3 Seat, RH |
| 79306 | Leg Sub Assy, NO.3 Seat, LH |
| 79319 | Bracket, NO.3 Seat Leg, RR RH |
| 79329 | Bracket, NO.3 Seat Leg, RR LH |
| 79335A | Pad, NO.3 Seat Cushion, RH |
| 79345A | Pad, NO.3 Seat Cushion, LH |
| 79360A | Spring Assy, NO.3 Seat Cushion, RH |
| 79370A | Spring Assy, NO.3 Seat Cushion, LH |
| 79372B | Cover, NO.2 Seat Front Bracket, RH |
| 79375A | Pad, NO.3 Seatback, RH |
| 79382D | Cover, NO.2 Seat Front Bracket, LH |
| 79385A | Pad, NO.3 Seatback, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
