Toyota Levin
2021-07 → present · chassis MZEA12,MZEH16 · catalogue 16C310 · General
Supported model
Data version 2023-06
Instrument Panel & Glove Compartment
47 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55011A | Garnish Sub-assy, Instrument Panel, NO.1 |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55300 | Panel Assy, Instrument, Upper |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55308B | Brace Sub-assy, Instrument Panel TO Cowl, NO.3 |
| 55312A | Clip, Instrument Panel |
| 55317E | Panel, Instrument Side, NO.1 |
| 55318F | Panel, Instrument Side, NO.2 |
| 55328 | Pin, Instrument Panel, NO.1 |
| 55328C | Pin, Instrument Panel, NO.2 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55349C | Cushion, Instrument Panel |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55357B | Cushion, Instrument Panel, NO.3 |
| 55358H | Protector, Instrument Panel |
| 55359A | Protector, Instrument Panel, NO.2 |
| 55395 | Bracket, Instrument Panel TO Pedal |
| 55400 | Pad Assy, Instrument Panel Safety |
| 55401F | Clip(FOR SAFETY PAD) |
| 55403F | Panel Sub-assy, Instrument Panel Finish |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55410C | Panel Assy, Instrument Cluster Finish |
| 55413D | Panel, Instrument Cluster Finish, Center Lower |
| 55416C | Retainer, Instrument Cluster Finish Panel |
| 55422C | Panel, Instrument Cluster Finish, Center Upper |
| 55432B | Panel, Instrument Panel Finish, Lower |
| 55433B | Panel, Instrument Panel Finish, Lower NO.2 |
| 55434F | Panel, Instrument Panel Finish, Lower Center |
| 55469B | Insert, Instrument Panel Lower Pad Sub |
| 55470 | Garnish Assy, Instrument Cluster Finish Panel |
| 55472C | Panel, Instrument Panel Speaker, NO.1 |
| 55473B | Panel, Instrument Panel Speaker, NO.2 |
| 55474B | Garnish, Instrument Cluster Finish Panel |
| 55475A | Garnish, Instrument Cluster Finish Panel, NO.2 |
| 55524 | Cover, Switch Bace Hole |
| 55539C | Cover, Spare Switch Hole |
| 55550 | Door Assy, Glove Compartment |
| 55557A | Cushion, Glove Compartment Door Check |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55607 | Cover Sub-assy, Instrument Panel Under, NO.2 |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670A | Register Assy, Instrument Panel, Center |
| 55961 | Nozzle, Side Defroster, NO.1 |
| 55962 | Nozzle, Side Defroster, NO.2 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
