Toyota BZ3
2023-01 → present · chassis BEAM10,BEJG10 · catalogue 182310 · General
Supported model
Data version 2024-06
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44510 — Actuator Assy, Brake | ||||
| 44050-03030 |
Actuator Assy, Brake
2024-07 → —
|
BEJG10 H | — | |
| 44050-03060 |
Actuator Assy, Brake
2024-07 → —
|
BEJG10 J,M,N | — | |
| 44050-03010 |
Actuator Assy, Brake
2023-01 → —
|
BEAM10 | — | |
| 44590 — Bracket Assy, Brake Actuator | ||||
| 44590-03010 |
Bracket Assy, Brake Actuator
2024-07 → —
|
BEJG10 | — | |
| 44590-03010 |
Bracket Assy, Brake Actuator
2023-01 → —
|
BEAM10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
