Toyota BZ3
2023-01 → present · chassis BEAM10,BEJG10 · catalogue 182310 · General
Supported model
Data version 2024-06
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 53728A — Bracket, Fender Apron, RH | ||||
| 55135-03010 |
Bracket, Fender Apron, RH
2024-07 → —
|
BEJG10 | — | |
| 55135-03010 |
Bracket, Fender Apron, RH
2023-01 → —
|
BEAM10 | — | |
| 53729A — Bracket, Fender Apron, LH | ||||
| 55136-03010 |
Bracket, Fender Apron, LH
2024-07 → —
|
BEJG10 | — | |
| 55136-03010 |
Bracket, Fender Apron, LH
2023-01 → —
|
BEAM10 | — | |
| 55101 — Panel Sub-assy, Dash | ||||
| 55101-03051 |
Panel Sub-assy, Dash
2024-07 → —
|
BEJG10 J,M,N | — | |
| 55101-03080 |
Panel Sub-assy, Dash
2024-07 → —
|
BEJG10 H | — | |
| 55101-03050 |
Panel Sub-assy, Dash
2023-01 → 2023-08
ended
|
BEAM10 | — | |
| 55101-03051 |
Panel Sub-assy, Dash
2023-09 → —
|
BEAM10 | — | |
| 55130 — Plate Assy, Fender Apron Set, RH | ||||
| 55130-03010 |
Plate Assy, Fender Apron Set, RH
2024-07 → —
|
BEJG10 | — | |
| 55130-03010 |
Plate Assy, Fender Apron Set, RH
2023-01 → —
|
BEAM10 | — | |
| 55133A — Reinforcement, Dash TO Floor, RH | ||||
| 55133-03010 |
Reinforcement, Dash TO Floor, RH
2024-07 → —
|
BEJG10 | — | |
| 55133-03010 |
Reinforcement, Dash TO Floor, RH
2023-01 → —
|
BEAM10 | — | |
| 55134A — Reinforcement, Dash TO Floor, LH | ||||
| 55134-03010 |
Reinforcement, Dash TO Floor, LH
2024-07 → —
|
BEJG10 | — | |
| 55134-03010 |
Reinforcement, Dash TO Floor, LH
2023-01 → —
|
BEAM10 | — | |
| 55140 — Plate Assy,Fender Apron Set, LH | ||||
| 55140-03010 |
Plate Assy,Fender Apron Set, LH
2024-07 → —
|
BEJG10 | — | |
| 55140-03010 |
Plate Assy,Fender Apron Set, LH
2023-01 → —
|
BEAM10 | — | |
| 55210 — Insulator Assy, Dash Panel | ||||
| 55210-03030 |
Insulator Assy, Dash Panel
2024-07 → —
|
BEJG10 J,M,N | — | |
| 55210-03050 |
Insulator Assy, Dash Panel
2024-07 → —
|
BEJG10 H | — | |
| 55210-03030 |
Insulator Assy, Dash Panel
2023-01 → —
|
BEAM10 | — | |
| 55210A — Clip | ||||
| 90467-11122 |
Clip
2024-07 → —
|
BEJG10 | — | |
| 90467-11122 |
Clip
2023-01 → —
|
BEAM10 | — | |
| 55223A — Insulator, Dash Panel, Outer | ||||
| 55223-03030 |
Insulator, Dash Panel, Outer
2024-07 → —
|
BEJG10 | — | |
| 55223-03020 |
Insulator, Dash Panel, Outer
2023-01 → —
|
BEAM10 | — | |
| 55223C — Clip | ||||
| 90467-06197 note |
Clip
2024-07 → —
|
BEJG10 | — | |
| 90467-C0080 note |
Clip
2024-07 → —
|
BEJG10 | — | |
| 90467-06197 |
Clip
2023-01 → 2024-02
ended
|
BEAM10 | — | |
| 90467-C0080 |
Clip
2024-02 → —
|
BEAM10 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
