Toyota BZ3C

2024-12 → present · chassis BEAG11 · catalogue 183210 · General

Supported model Data version 2024-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Panel & Glass

26 part groups · 2 illustrations

Illustrations

Figure 67D1NRA 67D1NRA 2024-12 → — Figure 67D1NSA 67D1NSA 2024-12 → —

Part groups

PNCDescription
62785F Spacer, Back Door Glass
64818B Spacer, Back Door Glass, NO.1
64819B Spacer, Back Window Glass, NO.2
67005 Panel Sub-assy, Back Door
67005B Cushion(FOR BACK DOOR PANEL)
67261A Plate, Back Door Reinforcement, NO.1 RH
67262A Plate, Back Door Reinforcement, NO.1 LH
67281G Stopper, Back Door, Lower RH
67282F Stopper, Back Door, Lwr LH
67293D Cushion, Back Door Stopper, RH
67294D Cushion, Back Door Stopper, LH
67372A Weight, Back Door
67750 Board Assy, Back Door Trim
67750A Clip(FOR BACK DOOR TRIM)
67766 Cover, Back Door Service Hole, NO.2
67837L Seal, Door Dust Proof
67881A Weatherstrip, Back Door
67937B Garnish, Back Door Side, RH
67937C Clip(FOR BACK DOOR SIDE GARNISH)
67938A Garnish, Back Door Side, LH
67939B Garnish, Back Door, Center
67939C Clip(FOR BACK DOOR CENTER GARNISH)
68131 Glass, Back Door
69212C Handle, Back Door Inside
69478 Cushion, Back Door Lower Stopper
75575D Moulding, Back Window, Lower
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
