Toyota Carina

1981-08 → 1983-09 · chassis TA6#,CA60 · catalogue 221230 · General

Discontinued model Data version 1984-02
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Heating & Air Conditioning - Heater Unit & Blower

9 part groups · 2 illustrations

Illustrations

Figure MEA598C MEA598C 1981-08 → — Figure MEA726C MEA726C 1981-08 → —

Part groups

PNCDescription
87104 Motor Sub-assy, Heater Blower
87105 Fan Sub-assy, Heater Blower
87107 Unit Sub-assy, Heater Radiator
87116 Spring, Heater Case Fastening
87116B Spring, Boost Ventilator Case
87130 Blower Assy, Heater, Front
87150 Radiator Assy, Heater
87188 Packing, Heater Blower Motor
88910 Ventilator Assy, Boost
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
