Toyota Prius

2022-12 → present · chassis MXWH61,ZVW60 · catalogue 222250 · General

Supported model Data version 2023-03
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

14 part groups · 2 illustrations

Illustrations

Figure 746581D 746581D 2022-12 → — Figure 746582A 746582A 2022-12 → —

Part groups

PNCDescription
11291B Plate, Engine Name
288A2 Label, Battery Location
42668 Label, Compact Spare Tire Caution
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515C Label, Theft Warning Information
74528J Label, Power Back Door Caution
7452A Label, Shift Control Information
74541E Plate, Compact Spare Tire Caution
74543P Label, Rear Seat Caution
74559B Label, Fuel Information
74573D Label, Electric Vehicle Battery Caution
74751 Label, Tire Pressure Information
88723H Label, Cooler Service Caution
88733A Label, Cooler Service Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
