Toyota Prius (CHINA)

2005-11 → 2009-04 · chassis NHW20 · catalogue 223310 · General

Discontinued model Data version 2009-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Suspension Crossmember & Under Cover

14 part groups · 2 illustrations

Illustrations

Figure 511395A 511395A 2005-11 → — Figure 511396 511396 2005-11 → —

Part groups

PNCDescription
51201 Crossmember Sub-assy, Front Suspension
51441C Cover, Engine Under, RH
51442C Cover, Engine Under, LH
51443B Cover, Engine Under, NO.3
51967B Hook, Transport, Rear RH
51968B Hook, Transport, Rear LH
52161Q Piece, Front Bumper
58165C Cover, Front Floor, RH
58166A Cover, Front Floor, LH
58167D Cover, Front Floor, Center RH
58168D Cover, Front Floor, Center LH
58227G Plate, Floor Panel Side, RH
58228H Plate, Floor Panel Side, LH
58398F Cover, Floor Under, NO.1
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
