Toyota Celica
1993-11 → 1999-08 · chassis ST20# · catalogue 252370 · General
Discontinued model
Data version 2000-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 31126 — Boot, Clutch Release Fork | ||||
| 31126-20080 |
Boot, Clutch Release Fork
1994-02 → —
|
ST205 | — | |
| 31126-32010 |
Boot, Clutch Release Fork
1993-11 → —
|
ST202,204 MTM | — | |
| 31204 — Fork Sub-assy, Clutch Release | ||||
| 31204-20100 |
Fork Sub-assy, Clutch Release
1993-11 → —
|
ST202,204 MTM | — | |
| 31204-20110 |
Fork Sub-assy, Clutch Release
1994-02 → 1996-02
ended
|
ST205 | — | |
| 31204-20111 |
Fork Sub-assy, Clutch Release
1996-02 → —
|
ST205 | — | |
| 31210 — Cover Assy, Clutch | ||||
| 31210-20350 |
Cover Assy, Clutch
1994-02 → —
|
ST205 | — | |
| 31210-32130 |
Cover Assy, Clutch
1993-11 → —
|
ST202,204 MTM | — | |
| 31230 — Bearing Assy, Clutch Release | ||||
| 31230-20190 |
Bearing Assy, Clutch Release
1994-02 → 1998-11
ended
|
ST205 | — | |
| 31230-20191 |
Bearing Assy, Clutch Release
1998-11 → —
|
ST205 | — | |
| 31230-32060 |
Bearing Assy, Clutch Release
1993-11 → —
|
ST202,204 MTM | — | |
| 31232A — Clip, Release Bearing Hub | ||||
| 31232-20020 note |
Clip, Release Bearing Hub
1993-11 → —
|
ST202,204 MTM | — | |
| 31232-20031 note |
Clip, Release Bearing Hub
1994-02 → —
|
ST205 | — | |
| 31232-32050 note |
Clip, Release Bearing Hub
1993-11 → —
|
ST202,204 MTM | — | |
| 31236B — Support, Release Fork | ||||
| 31236-20070 |
Support, Release Fork
1994-02 → —
|
ST205 | — | |
| 31236-32010 |
Support, Release Fork
1993-11 → —
|
ST202,204 MTM | — | |
| 31250 — Disc Assy, Clutch | ||||
| 31250-17040 |
Disc Assy, Clutch
1993-11 → 1996-07
ended
|
ST202,204 MTM | — | |
| 31250-17051 |
Disc Assy, Clutch
1994-02 → 1997-03
ended
|
ST205 | — | |
| 31250-17052 |
Disc Assy, Clutch
1997-03 → —
|
ST205 | — | |
| 31250-20250 |
Disc Assy, Clutch
1996-07 → 1997-12
ended
|
ST202,204 MTM | — | |
| 31250-20250 |
Disc Assy, Clutch
1997-12 → 1998-12
ended
|
ST202 MTM | — | |
| 31250-20251 |
Disc Assy, Clutch
1998-12 → —
|
ST202 MTM | — | |
| 31250-20330 |
Disc Assy, Clutch
1997-12 → 1998-12
ended
|
ST204 MTM | — | |
| 31250-20331 |
Disc Assy, Clutch
1998-12 → —
|
ST204 MTM | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
