Toyota Celica
1993-11 → 1999-08 · chassis ST20# · catalogue 252370 · General
Discontinued model
Data version 2000-03
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04438H — Boot Kit, Front Drive Shaft, IN & Outboard, LH | ||||
| 04438-20130 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1993-11 → 1998-04
ended
|
ST204 ATM | — | |
| 04438-20131 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1998-04 → —
|
ST204 ATM | — | |
| 04438-20150 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1993-11 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 04438-20270 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1994-02 → 1995-02
ended
|
ST205 | — | |
| 04438-20280 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1995-02 → —
|
ST205 | — | |
| 04438-20370 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1998-05 → 1998-09
ended
|
ST202;ST204 MTM | — | |
| 04438-20371 |
Boot Kit, Front Drive Shaft, IN & Outboard, LH
1998-09 → —
|
ST202;ST204 MTM | — | |
| 04438J — Boot Kit, Front Drive Shaft Inboard Joint, LH | ||||
| 04438-20120 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
1993-11 → 1998-04
ended
|
ST204 ATM | — | |
| 04438-20121 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
1998-04 → —
|
ST204 ATM | — | |
| 04438-20140 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
1993-11 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 04438-20260 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
1994-02 → —
|
ST205 | — | |
| 04438-20360 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
1998-05 → 1998-09
ended
|
ST202;ST204 MTM | — | |
| 04438-20361 |
Boot Kit, Front Drive Shaft Inboard Joint, LH
1998-09 → —
|
ST202;ST204 MTM | — | |
| 41336E — Cover, Front Drive Shaft Dust, LH | ||||
| 41336-17020 |
Cover, Front Drive Shaft Dust, LH
1994-02 → —
|
ST205 | — | |
| 41336-32020 |
Cover, Front Drive Shaft Dust, LH
1993-11 → —
|
ST202,204 | — | |
| 43040 — Joint Assy, Front Drive Inboard, LH | ||||
| 43040-20010 |
Joint Assy, Front Drive Inboard, LH
1993-11 → 1998-06
ended
|
ST204 ATM | — | |
| 43040-20020 |
Joint Assy, Front Drive Inboard, LH
1993-11 → —
|
ST202;ST204 MTM | — | |
| 43040-20040 |
Joint Assy, Front Drive Inboard, LH
1994-02 → —
|
ST205 | — | |
| 43040-32040 |
Joint Assy, Front Drive Inboard, LH
1998-06 → —
|
ST204 ATM | — | |
| 43247C — Deflector, Front Wheel Bearing Dust, LH NO.2 | ||||
| 43247-12010 note |
Deflector, Front Wheel Bearing Dust, LH NO.2
1993-11 → —
|
ST20# | — | |
| 43247-33010 |
Deflector, Front Wheel Bearing Dust, LH NO.2
1993-11 → —
|
ST202,204 | — | |
| 43412B — Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER LH) | ||||
| 90520-22005 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER LH)
1993-11 → —
|
ST204 ATM | — | |
| 90520-25034 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER LH)
1994-02 → —
|
ST205 | — | |
| 90520-26048 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT INNER LH)
1993-11 → —
|
ST202;ST204 MTM | — | |
| 43412C — Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT OUTER LH) | ||||
| 90520-25037 |
Ring, Shaft Snap (FOR FRONT DRIVE INNER SHAFT OUTER LH)
1993-11 → —
|
ST202;ST204 MTM | — | |
| 43420 — Shaft Assy, Front Drive, LH | ||||
| 43420-20390 note |
Shaft Assy, Front Drive, LH
1993-11 → 1997-09
ended
|
ST204 ATM | — | |
| 43420-20391 note |
Shaft Assy, Front Drive, LH
1997-09 → 1999-01
ended
|
ST204 ATM | — | |
| 43420-20392 note |
Shaft Assy, Front Drive, LH
1999-01 → —
|
ST204 ATM | — | |
| 43420-20410 |
Shaft Assy, Front Drive, LH
1994-02 → 1995-02
ended
|
ST205 | — | |
| 43420-20430 |
Shaft Assy, Front Drive, LH
1993-11 → 1997-12
ended
|
ST202;ST204 MTM | — | |
| 43420-20431 |
Shaft Assy, Front Drive, LH
1997-12 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 43420-20432 |
Shaft Assy, Front Drive, LH
1998-05 → —
|
ST202;ST204 MTM | — | |
| 43420-20440 note |
Shaft Assy, Front Drive, LH
1993-11 → 1997-12
ended
|
ST202;ST204 MTM | — | |
| 43420-20441 note |
Shaft Assy, Front Drive, LH
1997-12 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 43420-20442 note |
Shaft Assy, Front Drive, LH
1998-05 → —
|
ST202;ST204 MTM | — | |
| 43420-20490 |
Shaft Assy, Front Drive, LH
1993-11 → 1997-09
ended
|
ST204 ATM | — | |
| 43420-20491 |
Shaft Assy, Front Drive, LH
1997-09 → 1999-01
ended
|
ST204 ATM | — | |
| 43420-20492 |
Shaft Assy, Front Drive, LH
1999-01 → —
|
ST204 ATM | — | |
| 43420-20520 |
Shaft Assy, Front Drive, LH
1995-02 → 1996-04
ended
|
ST205 | — | |
| 43420-20521 |
Shaft Assy, Front Drive, LH
1996-04 → —
|
ST205 | — | |
| 43420G — Ring, Hole Snap (FOR FRONT DRIVE SHAFT LH) | ||||
| 90521-26004 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT LH)
1994-02 → —
|
ST205 | — | |
| 90521-27005 |
Ring, Hole Snap (FOR FRONT DRIVE SHAFT LH)
1993-11 → —
|
ST202,204 | — | |
| 43447E — Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH) | ||||
| 42345-16030 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → 1997-09
ended
|
ST204 ATM | — | |
| 42345-16030 note |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1997-09 → 1999-01
ended
|
ST204 ATM | — | |
| 42345-16030 note |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → —
|
ST204 ATM | — | |
| 42345-16040 note |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → —
|
ST204 ATM | — | |
| 42345-16050 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 42345-16060 note |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 42345-20040 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1998-05 → —
|
ST202;ST204 MTM | — | |
| 42345-20090 note |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1999-01 → —
|
ST204 ATM | — | |
| 42345-20100 note |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1999-01 → —
|
ST204 ATM | — | |
| 90949-01938 |
Clamp (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1994-02 → —
|
ST205 | — | |
| 43447F — Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH) | ||||
| 42345-16040 note |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → 1999-01
ended
|
ST204 ATM | — | |
| 42345-16060 |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1993-11 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 42345-20030 |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1998-05 → —
|
ST202;ST204 MTM | — | |
| 42345-20110 note |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1999-01 → —
|
ST204 ATM | — | |
| 42345-20120 note |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1999-01 → —
|
ST204 ATM | — | |
| 90949-01937 |
Clamp, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
1994-02 → —
|
ST205 | — | |
| 43448F — Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH) | ||||
| 42345-16010 |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → —
|
ST204 ATM | — | |
| 42345-16040 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → —
|
ST204 ATM | — | |
| 42345-16050 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 42345-16050 |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → —
|
ST202;ST204 MTM | — | |
| 42345-16090 note |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → —
|
ST202;ST204 MTM | — | |
| 90949-01108 |
Clamp (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1994-02 → —
|
ST205 | — | |
| 43448G — Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH) | ||||
| 42345-16040 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → 1999-08
ended
|
ST204 ATM | — | |
| 42345-30010 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1993-11 → 1999-08
ended
|
ST202;ST204 MTM | — | |
| 42346-22010 |
Clamp, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH)
1994-02 → 1999-08
ended
|
ST205 | — | |
| 43470 — Shaft Assy, Front Drive Outboard Joint, LH | ||||
| 43470-29325 note |
Shaft Assy, Front Drive Outboard Joint, LH
1993-11 → 1997-12
ended
|
ST202;ST204 MTM | — | |
| 43470-29326 note |
Shaft Assy, Front Drive Outboard Joint, LH
1997-12 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 43470-29327 note |
Shaft Assy, Front Drive Outboard Joint, LH
1998-05 → 1998-06
ended
|
ST202;ST204 MTM | — | |
| 43470-29328 note |
Shaft Assy, Front Drive Outboard Joint, LH
1998-06 → —
|
ST202;ST204 MTM | — | |
| 43470-29335 note |
Shaft Assy, Front Drive Outboard Joint, LH
1993-11 → 1997-09
ended
|
ST204 ATM | — | |
| 43470-29336 note |
Shaft Assy, Front Drive Outboard Joint, LH
1997-09 → 1998-04
ended
|
ST204 ATM | — | |
| 43470-29337 note |
Shaft Assy, Front Drive Outboard Joint, LH
1998-04 → 1999-01
ended
|
ST204 ATM | — | |
| 43470-29338 note |
Shaft Assy, Front Drive Outboard Joint, LH
1999-01 → —
|
ST204 ATM | — | |
| 43470-29365 |
Shaft Assy, Front Drive Outboard Joint, LH
1993-11 → 1997-12
ended
|
ST202;ST204 MTM | — | |
| 43470-29366 |
Shaft Assy, Front Drive Outboard Joint, LH
1997-12 → 1998-05
ended
|
ST202;ST204 MTM | — | |
| 43470-29367 |
Shaft Assy, Front Drive Outboard Joint, LH
1998-05 → 1998-06
ended
|
ST202;ST204 MTM | — | |
| 43470-29368 |
Shaft Assy, Front Drive Outboard Joint, LH
1998-06 → —
|
ST202;ST204 MTM | — | |
| 43470-29375 |
Shaft Assy, Front Drive Outboard Joint, LH
1993-11 → 1997-09
ended
|
ST204 ATM | — | |
| 43470-29376 |
Shaft Assy, Front Drive Outboard Joint, LH
1997-09 → 1998-04
ended
|
ST204 ATM | — | |
| 43470-29377 |
Shaft Assy, Front Drive Outboard Joint, LH
1998-04 → 1999-01
ended
|
ST204 ATM | — | |
| 43470-29378 |
Shaft Assy, Front Drive Outboard Joint, LH
1999-01 → —
|
ST204 ATM | — | |
| 43470-29455 |
Shaft Assy, Front Drive Outboard Joint, LH
1994-02 → 1995-02
ended
|
ST205 | — | |
| 43470-29465 |
Shaft Assy, Front Drive Outboard Joint, LH
1995-02 → 1996-04
ended
|
ST205 | — | |
| 43470-29466 |
Shaft Assy, Front Drive Outboard Joint, LH
1996-04 → —
|
ST205 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
