Toyota Celica
1993-11 → 1999-08 · chassis ST20# · catalogue 252370 · General
Discontinued model
Data version 2000-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 87019C — Grommet, Heater Hose | ||||
| 90480-01405 |
Grommet, Heater Hose
1993-11 → —
|
ST20# RHD | — | |
| 90480-01659 note |
Grommet, Heater Hose
1993-11 → —
|
ST202 LHD | — | |
| 90480-36011 note |
Grommet, Heater Hose
1993-11 → —
|
ST202 LHD | — | |
| 87240 — Valve Assy, Heater Water | ||||
| 87240-20410 |
Valve Assy, Heater Water
1993-11 → —
|
ST20# RHD | — | |
| 87240-20420 |
Valve Assy, Heater Water
1993-11 → —
|
ST202 LHD | — | |
| 87245A — Hose, Heater Water, Inlet A | ||||
| 87245-2D020 |
Hose, Heater Water, Inlet A
1993-11 → 1995-08
ended
|
ST202,204 RHD | — | |
| 87245-2D040 |
Hose, Heater Water, Inlet A
1993-11 → 1995-08
ended
|
ST202 LHD | — | |
| 87245-2D060 |
Hose, Heater Water, Inlet A
1994-02 → —
|
ST205 | — | |
| 87245-2D260 |
Hose, Heater Water, Inlet A
1995-08 → —
|
ST202,204 RHD | — | |
| 87245-2D280 |
Hose, Heater Water, Inlet A
1995-08 → —
|
ST202 LHD | — | |
| 87245E — Hose, Heater Water, Inlet E | ||||
| 87245-2B510 |
Hose, Heater Water, Inlet E
1993-11 → —
|
ST20# RHD | — | |
| 99556-30100 note |
Hose, Heater Water, Inlet E
1993-11 → —
|
ST202 LHD | — | |
| 87246E — Hose, Heater Water, Outlet E | ||||
| 87245-2D030 |
Hose, Heater Water, Outlet E
1993-11 → 1995-08
ended
|
ST202,204 RHD | — | |
| 87245-2D050 |
Hose, Heater Water, Outlet E
1993-11 → 1995-08
ended
|
ST202 LHD | — | |
| 87245-2D070 |
Hose, Heater Water, Outlet E
1994-02 → —
|
ST205 | — | |
| 87245-2D270 |
Hose, Heater Water, Outlet E
1995-08 → —
|
ST202,204 RHD | — | |
| 87245-2D290 |
Hose, Heater Water, Outlet E
1995-08 → —
|
ST202 LHD | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
