Toyota Celica
1993-11 → 1999-08 · chassis ST20# · catalogue 252370 · General
Discontinued model
Data version 2000-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 87810 — Mirror Assy, Inner Rear View | ||||
| 87810-01040-B0 note |
Mirror Assy, Inner Rear View
1993-11 → 1994-05
ended
|
ST20# | — | |
| 87810-01040-B0 note |
Mirror Assy, Inner Rear View
1994-10 → 1995-08
ended
|
ST20# | — | |
| 87810-01040-B3 note |
Mirror Assy, Inner Rear View
1995-08 → —
|
ST20# ARL,GEN | — | |
| 87810-12240-B3 note |
Mirror Assy, Inner Rear View
1995-08 → —
|
ST20# ARL,GEN | — | |
| 87810-12240-S3 note |
Mirror Assy, Inner Rear View
1993-11 → 1995-08
ended
|
ST20# | — | |
| 87810-12260-B3 note |
Mirror Assy, Inner Rear View
1995-08 → —
|
ST202 GCC | — | |
| 87816 — Spring, Inner Rear View Mirror | ||||
| 74372-01020 note |
Spring, Inner Rear View Mirror
1993-11 → 1995-08
ended
|
ST20# | — | |
| 74372-01020 note |
Spring, Inner Rear View Mirror
1995-08 → —
|
ST20# ARL,GEN | — | |
| 74372-30030 note |
Spring, Inner Rear View Mirror
1993-11 → 1995-08
ended
|
ST20# | — | |
| 74372-30030 |
Spring, Inner Rear View Mirror
1995-08 → —
|
ST202 GCC | — | |
| 74372-30030 note |
Spring, Inner Rear View Mirror
1995-08 → —
|
ST20# ARL,GEN | — | |
| 87834 — Cover, Inner Rear View Mirror Stay Holder | ||||
| 87834-12030-B4 note |
Cover, Inner Rear View Mirror Stay Holder
1995-08 → —
|
ST20# | — | |
| 87834-12030-S3 note |
Cover, Inner Rear View Mirror Stay Holder
1993-11 → 1995-08
ended
|
ST20# | — | |
| 87901B — Mirror Sub-assy, Outer Rear View, RH | ||||
| 87931-2B760 |
Mirror Sub-assy, Outer Rear View, RH
1996-06 → —
|
ST202 GEN | — | |
| 87931-2B760 |
Mirror Sub-assy, Outer Rear View, RH
1993-11 → 1996-06
ended
|
ST202 | — | |
| 87931-2B810 |
Mirror Sub-assy, Outer Rear View, RH
1993-11 → —
|
ST204,205 | — | |
| 87931-2D130 |
Mirror Sub-assy, Outer Rear View, RH
1996-06 → —
|
ST202 GCC | — | |
| 87906B — Mirror Sub-assy, Outer Rear View, LH | ||||
| 87961-2D020 |
Mirror Sub-assy, Outer Rear View, LH
1993-11 → 1996-06
ended
|
ST20# | — | |
| 87961-2D020 |
Mirror Sub-assy, Outer Rear View, LH
1996-06 → —
|
ST20# ARL,GEN | — | |
| 87961-2D130 |
Mirror Sub-assy, Outer Rear View, LH
1996-06 → —
|
ST202 GCC | — | |
| 87910 — Mirror Assy, Outer Rear View, RH | ||||
| 87910-2B760-A0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST202 RHD | — | |
| 87910-2B760-B0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST202 RHD | — | |
| 87910-2B760-C0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST202 RHD | — | |
| 87910-2B760-D0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST202 RHD | — | |
| 87910-2B760-D1 note |
Mirror Assy, Outer Rear View, RH
1997-01 → —
|
ST202 RHD | — | |
| 87910-2B760-F0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1995-08
ended
|
ST202 RHD | — | |
| 87910-2B760-H0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1995-08
ended
|
ST202 RHD | — | |
| 87910-2B760-H2 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1994-08
ended
|
ST202 RHD | — | |
| 87910-2B760-H3 note |
Mirror Assy, Outer Rear View, RH
1995-08 → 1997-01
ended
|
ST202 RHD | — | |
| 87910-2B760-J0 note |
Mirror Assy, Outer Rear View, RH
1994-08 → 1996-06
ended
|
ST202 RHD | — | |
| 87910-2B760-J1 note |
Mirror Assy, Outer Rear View, RH
1995-08 → 1997-12
ended
|
ST202 RHD | — | |
| 87910-2B760-J2 note |
Mirror Assy, Outer Rear View, RH
1997-12 → 1998-07
ended
|
ST202 RHD | — | |
| 87910-2B760-K0 note |
Mirror Assy, Outer Rear View, RH
1996-06 → —
|
ST202 RHD | — | |
| 87910-2B790 |
Mirror Assy, Outer Rear View, RH
1996-06 → —
|
ST202 LHD GEN | — | |
| 87910-2B790 |
Mirror Assy, Outer Rear View, RH
1993-11 → 1996-06
ended
|
ST202 LHD | — | |
| 87910-2B810-A0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST204,205 | — | |
| 87910-2B810-B0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST204,205 | — | |
| 87910-2B810-B1 note |
Mirror Assy, Outer Rear View, RH
1995-08 → 1997-12
ended
|
ST204,205 | — | |
| 87910-2B810-C0 note |
Mirror Assy, Outer Rear View, RH
1995-08 → —
|
ST204 | — | |
| 87910-2B810-D0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → —
|
ST204,205 | — | |
| 87910-2B810-D1 note |
Mirror Assy, Outer Rear View, RH
1997-01 → —
|
ST204 | — | |
| 87910-2B810-F0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1995-08
ended
|
ST204 | — | |
| 87910-2B810-G0 note |
Mirror Assy, Outer Rear View, RH
1997-12 → 1998-07
ended
|
ST204,205 | — | |
| 87910-2B810-H0 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1995-08
ended
|
ST204,205 | — | |
| 87910-2B810-H1 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1994-08
ended
|
ST204 | — | |
| 87910-2B810-H2 note |
Mirror Assy, Outer Rear View, RH
1993-11 → 1995-08
ended
|
ST204 | — | |
| 87910-2B810-H3 note |
Mirror Assy, Outer Rear View, RH
1995-08 → 1997-01
ended
|
ST204 | — | |
| 87910-2B810-J0 note |
Mirror Assy, Outer Rear View, RH
1994-08 → 1996-06
ended
|
ST204 | — | |
| 87910-2B810-J1 note |
Mirror Assy, Outer Rear View, RH
1999-01 → 1999-07
ended
|
ST204 | — | |
| 87910-2B810-K0 note |
Mirror Assy, Outer Rear View, RH
1996-06 → —
|
ST204 | — | |
| 87910-2D130 |
Mirror Assy, Outer Rear View, RH
1996-06 → —
|
ST202 GCC | — | |
| 87940 — Mirror Assy, Outer Rear View, LH | ||||
| 87940-2B790 |
Mirror Assy, Outer Rear View, LH
1996-06 → —
|
ST202 LHD GEN | — | |
| 87940-2B790 |
Mirror Assy, Outer Rear View, LH
1993-11 → 1996-06
ended
|
ST202 LHD | — | |
| 87940-2D020-A0 note |
Mirror Assy, Outer Rear View, LH
1993-11 → —
|
ST20# RHD | — | |
| 87940-2D020-B0 note |
Mirror Assy, Outer Rear View, LH
1993-11 → —
|
ST20# RHD | — | |
| 87940-2D020-B1 note |
Mirror Assy, Outer Rear View, LH
1995-08 → 1997-12
ended
|
ST204,205 | — | |
| 87940-2D020-C0 note |
Mirror Assy, Outer Rear View, LH
1993-11 → 1995-08
ended
|
ST202 RHD | — | |
| 87940-2D020-C0 note |
Mirror Assy, Outer Rear View, LH
1995-08 → —
|
ST202,204 RHD | — | |
| 87940-2D020-D0 note |
Mirror Assy, Outer Rear View, LH
1993-11 → —
|
ST20# RHD | — | |
| 87940-2D020-D1 note |
Mirror Assy, Outer Rear View, LH
1997-01 → —
|
ST202,204 RHD | — | |
| 87940-2D020-F0 note |
Mirror Assy, Outer Rear View, LH
1993-11 → 1995-08
ended
|
ST202,204 RHD | — | |
| 87940-2D020-G1 note |
Mirror Assy, Outer Rear View, LH
1997-12 → 1998-07
ended
|
ST204,205 | — | |
| 87940-2D020-H0 note |
Mirror Assy, Outer Rear View, LH
1993-11 → 1995-08
ended
|
ST20# RHD | — | |
| 87940-2D020-H1 note |
Mirror Assy, Outer Rear View, LH
1993-11 → 1995-08
ended
|
ST204 | — | |
| 87940-2D020-H2 note |
Mirror Assy, Outer Rear View, LH
1993-11 → 1994-08
ended
|
ST202,204 RHD | — | |
| 87940-2D020-H3 note |
Mirror Assy, Outer Rear View, LH
1995-08 → 1997-01
ended
|
ST202,204 RHD | — | |
| 87940-2D020-J0 note |
Mirror Assy, Outer Rear View, LH
1994-08 → 1996-06
ended
|
ST202,204 RHD | — | |
| 87940-2D020-J1 note |
Mirror Assy, Outer Rear View, LH
1995-08 → 1997-12
ended
|
ST202 RHD | — | |
| 87940-2D020-J2 note |
Mirror Assy, Outer Rear View, LH
1997-12 → 1998-07
ended
|
ST202 RHD | — | |
| 87940-2D020-J3 note |
Mirror Assy, Outer Rear View, LH
1999-01 → 1999-07
ended
|
ST204 | — | |
| 87940-2D020-K0 note |
Mirror Assy, Outer Rear View, LH
1996-06 → —
|
ST202,204 RHD | — | |
| 87940-2D130 |
Mirror Assy, Outer Rear View, LH
1996-06 → —
|
ST202 GCC | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
