Toyota Celica
1993-11 → 1999-08 · chassis ST20# · catalogue 252370 · General
Discontinued model
Data version 2000-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82151 — Wire, Front Door, RH | ||||
| 82151-2D740 note |
Wire, Front Door, RH
1993-11 → 1995-08
ended
|
ST202 LHD | — | |
| 82151-2D830 |
Wire, Front Door, RH
1993-11 → 1995-08
ended
|
ST202 RHD | — | |
| 82151-2D860 note |
Wire, Front Door, RH
1993-11 → 1995-08
ended
|
ST20# RHD | — | |
| 82151-2G020 |
Wire, Front Door, RH
1993-11 → 1995-08
ended
|
ST202 LHD | — | |
| 82151-2G220 |
Wire, Front Door, RH
1995-08 → —
|
ST20# RHD | — | |
| 82151-2G260 |
Wire, Front Door, RH
1995-08 → —
|
ST202 LHD | — | |
| 82152 — Wire, Front Door, LH | ||||
| 82152-2D570 note |
Wire, Front Door, LH
1993-11 → 1995-08
ended
|
ST202 LHD | — | |
| 82152-2D650 |
Wire, Front Door, LH
1993-11 → 1995-08
ended
|
ST202 LHD | — | |
| 82152-2D670 |
Wire, Front Door, LH
1993-11 → 1995-08
ended
|
ST202 RHD | — | |
| 82152-2D690 note |
Wire, Front Door, LH
1993-11 → 1995-08
ended
|
ST20# RHD | — | |
| 82152-2G040 |
Wire, Front Door, LH
1995-08 → —
|
ST20# RHD | — | |
| 82152-2G070 |
Wire, Front Door, LH
1995-08 → —
|
ST202 LHD | — | |
| 82171 — Wire, Roof, NO.1 | ||||
| 82171-20840 |
Wire, Roof, NO.1
1993-11 → —
|
ST202 LHD | — | |
| 82171-20850 |
Wire, Roof, NO.1
1993-11 → —
|
ST20# RHD | — | |
| 82171-20860 note |
Wire, Roof, NO.1
1993-11 → —
|
ST202 LHD | — | |
| 82171-20870 note |
Wire, Roof, NO.1
1993-11 → —
|
ST20# RHD | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
