Toyota Corona
1997-10 → 2003-10 · chassis AT220,CT220,ST220 · catalogue 273340 · General
Discontinued model
Data version 2003-10
Roof Panel & Back Window Glass
38 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 56115B | Stopper, Back Window Glass, NO.1 |
| 63102 | Reinforcement Sub-assy, Roof Panel, Front |
| 63102A | Panel Sub-assy, Windshield Header |
| 63111 | Panel, Roof |
| 63133A | Frame, Back Window, Upper |
| 63141H | Reinforcement, Roof Panel, Center |
| 63143B | Reinforcement, Roof Panel, NO.3 |
| 63144A | Reinforcement, Roof Panel, NO.4 |
| 63169B | Plate, Roof Panel Reinforcement, RH |
| 63179 | Plate, Roof Panel Reinforcement, LH |
| 63201G | Glass Sub-assy, Sliding Roof |
| 63206G | Gear Sub-assy, Sliding Roof Drive |
| 63207G | Rail Sub-assy, Sliding Roof Guide |
| 63209 | Panel Sub-assy, Roof Wind Deflector |
| 63214F | Channel, Roof Drip, Rear |
| 63223 | Cable, Sliding Roof Drive, RH |
| 63224 | Cable, Sliding Roof Drive, LH |
| 63228D | Clip, Roof Window Deflector Panel Guide |
| 63229A | Stopper, Sliding Roof Sunshade |
| 63233B | Frame, Sliding Roof Housing, RH |
| 63234B | Frame, Sliding Roof Housing, LH |
| 63241A | Bracket, Sliding Roof Housing Front Mounting, RH |
| 63245D | Bracket, Sliding Roof Housing Rear Mounting, RH |
| 63249E | Hose, Sliding Roof Drain |
| 63249F | Hose, Sliding Roof Drain |
| 63255 | Cover, Sliding Roof Guide Rail, RH |
| 63255F | Cover, Slide Roof Motor |
| 63256 | Cover, Sliding Roof Guide Rail, LH |
| 63257E | Holder, Sliding Roof Guide Rail, RH |
| 63258G | Holder, Sliding Roof Guide Rail, LH |
| 63261C | Shoe, Sliding Roof, Front RH |
| 63262 | Shoe, Sliding Roof, Front LH |
| 63275C | Box, Sliding Roof Drive Gear |
| 64101 | Panel Sub-assy, Upper Back |
| 64312B | Bracket, Package Tray, RH |
| 64313B | Bracket, Package Tray, LH |
| 64811 | Glass, Back Window |
| 64813D | Dam, Back Window Glass Adhesive |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
