Toyota Avensis
2003-01 → 2008-11 · chassis AZT250 · catalogue 273350 · General
Supported model
Data version 2009-04
Front Seat & Seat Track
56 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71100S | Seat Assy, Front RH |
| 71200S | Seat Assy, Front LH |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71537C | Protector, Front Seat Cushion Edge, RH |
| 71537D | Protector, Front Seat Cushion Edge, LH |
| 71610S | Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71620S | Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812D | Shield, Front Seat Cushion, LH |
| 71861 | Shield, Front Seat Cushion, Inner RH |
| 71862 | Shield, Front Seat Cushion, Inner LH |
| 71867A | Shield, Front Seat Cushion, Inner NO.1 RH |
| 71868A | Shield, Front Seat Cushion, Inner NO.1 LH |
| 71875A | Cover, Reclining Adjuster Inside, RH |
| 71875B | Cover, Reclining Adjuster Inside, RH |
| 71876 | Cover, Reclining Adjuster Inside, LH |
| 71876A | Cover, Reclining Adjuster Inside, LH |
| 71910A | Headrest Assy, Front Seat |
| 71931 | Support, Front Seat Headrest |
| 72010 | Adjuster Assy, Front Seat, RH |
| 72020 | Adjuster Assy, Front Seat, LH |
| 72125A | Cover, Seat Track, Upper Rear |
| 72137B | Cover, Seat Track, RH |
| 72138B | Cover, Seat Track, LH |
| 72157A | Cover, Seat Track Bracket, Inner RH |
| 72158 | Cover, Seat Track Bracket, Inner LH |
| 72407A | Housing Sub-assy, Front Seat Reclining, LH |
| 72407B | Housing Sub-assy, Front Seat Reclining RH |
| 72457 | Knob, Vertical Seat Adjuster |
| 72457D | Knob, Vertical Seat Adjuster, LH |
| 72459 | Cap, Vertical Seat Adjuster Knob |
| 72459A | Cap, Vertical Seat Adjuster Knob |
| 72497 | Cover, Vertical Adjuster Bracket, Outer |
| 72497A | Cover, Vertical Adjuster Bracket, Inner |
| 72497C | Cover, Vertical Adjuster Bracket, Outer |
| 72497D | Cover, Vertical Adjuster Bracket, Inner |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526 | Handle, Reclining Adjuster Release, LH |
| 72543 | Plate, Reclining Control, RH |
| 72544 | Plate, Reclining Control, LH |
| 72572B | Cap, Reclining Adjuster Knob, RH |
| 72572C | Cap, Reclining Adjuster Knob, LH |
| 72573 | Lever, Reclining Control, RH |
| 72574 | Lever, Reclining Control, LH |
| 72750D | Adjuster Assy, Lumbar Support, RH |
| 72760D | Adjuster Assy, Lumbar Support, LH |
| 85820Y | Motor Assy, Power Seat |
| 85820Z | Motor Assy, Power Seat |
| 85821 | Motor Assy, Power Seat |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
