Toyota Camry/Hybrid (CHINA)
2011-12 → 2017-11 · chassis ACV51,ASV5#,AVV50 · catalogue 280320 · General
Supported model
Data version 2018-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| G9277 — Label, Battery Caution, NO.2 | ||||
| G9277-47020 |
Label, Battery Caution, NO.2
2012-05 → 2015-01
ended
|
AVV50 | — | |
| G9277-47020 |
Label, Battery Caution, NO.2
2015-01 → —
|
AVV50 | — | |
| G9295C — Striker, Battery Cover Lock, NO.2 | ||||
| G9295-30020 |
Striker, Battery Cover Lock, NO.2
2012-05 → 2015-01
ended
|
AVV50 | — | |
| G9295-30020 |
Striker, Battery Cover Lock, NO.2
2015-01 → —
|
AVV50 | — | |
| G92X2 — Wire, HV Battery Pack, NO.2 | ||||
| G92X2-33010 |
Wire, HV Battery Pack, NO.2
2012-05 → 2015-01
ended
|
AVV50 | — | |
| G92X2-33010 |
Wire, HV Battery Pack, NO.2
2015-01 → —
|
AVV50 | — | |
| G9510 — Battery Assy, HV Supply | ||||
| G9510-33060 |
Battery Assy, HV Supply
2012-05 → 2015-01
ended
|
AVV50 | — | |
| G9510-33060 |
Battery Assy, HV Supply
2015-01 → —
|
AVV50 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
