Toyota Lexus ES300
2001-07 → 2006-03 · chassis MCV30 · catalogue 282370 · General
Discontinued model
Data version 2006-10
Caution Plate (EXTERIOR & INTERIOR)
17 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 11278B | Label, Engine Emission Compliance Information |
| 11289B | Label, Spark Plug Notice |
| 11298B | Label, Emission Control Information |
| 47996C | Label, Brake Bleed Caution |
| 69339C | Label, Child Protector Information |
| 74511F | Label, Name (IDENTIFICATION LASER LABEL) |
| 74515A | Plate, Theft Warning |
| 74533E | Label, Headlamp Voltage Caution |
| 74559A | Plate, Fuel Caution |
| 74571A | Film, Label Cover |
| 74596A | Label, Side Airbag Caution |
| 74597 | Label, Driver & Passenger Airbag Caution |
| 74598A | Label, Passenger Airbag Caution |
| 74751 | Label, Tire Pressure Information |
| 85539D | Label, Power Outlet Notice |
| 87529B | Label, A/C Filter Information |
| 88723E | Label, Cooler Service Caution |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
