Toyota Camry

2015-04 → 2017-06 · chassis ASV50 · catalogue 283390 · General

Supported model Data version 2017-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Headlining & Silencer Pad

18 part groups · 2 illustrations

Illustrations

Figure 643594A 643594A 2015-04 → — Figure 643595A 643595A 2015-04 → —

Part groups

PNCDescription
63306 Trim Sub-assy, Sunshade
63310 Headlining Assy, Roof
63310D Clip, Roof Headlining
63310H Clip(FOR ROOF HEADLINING)
63310L Cap(FOR ROOF HEADLINING)
63318C Moulding, Sun Roof Opening Trim
63342 Pad, Roof Silencer, NO.2
63344H Pad, Roof Silencer, NO.4
63347B Pad, Roof Side Rail Silencer, RH
63348B Pad, Roof Side Rail Silencer, LH
63395 Clip, Roof Headlining Trim
63650A Box Assy, Roof Console
63660D Lock Assy, Roof Console
63665C Mat, Roof Console Box
66415B Spacer, Side Rail, Rear NO.2 RH
66416 Spacer, Side Rail, Rear NO.3 RH
66425B Spacer, Side Rail, Rear NO.2 LH
66426B Spacer, Side Rail, Rear NO.3 LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
