Toyota Camry

2002-03 → 2006-11 · chassis ACV30,31,MCV30 · catalogue 284370 · General

Discontinued model Data version 2007-04

Instrument Panel & Glove Compartment

37 part groups · 8 illustrations

PNC	Description
55054	Stopper Sub-assy, Glove Compartment Door
55061	Register Sub-assy, Instrument Panel, NO.1
55062	Register Sub-assy, Instrument Panel, N0.2
55302A	Panel Sub-assy, Instrument, Upper
55303B	Panel Sub-assy, Instrument, Lower
55306A	Brace Sub-assy, Instrument Panel, NO.1
55307C	Brace Sub-assy, Instrument Panel, NO.2
55308C	Bracket Sub-assy, Instrument Panel, Center
55331	Reinforcement, Instrument Panel
55394B	Bolt, Instrument Panel
55401E	Pad Sub-assy, Instrument Panel Safety
55405B	Panel Sub-assy, Instrument Cluster Finish, Center
55408E	Box Sub-assy, Instrument Panel Coin
55409A	Panel Sub-assy, Instrument Panel Speaker
55409F	Panel Sub-assy, Instrument Panel Speaker, NO.2
55409G	Retainer Sub-assy, Coin Box
55411G	Panel, Instrument Cluster Finish, NO.1
55434B	Panel, Instrument Panel Finish, Lower Center
55437A	Retainer, Instrument Panel Finish Panel, NO.1
55446A	Base, Switch Hole, NO.1
55458A	Cap, Instrument Panel Safety Pad
55510	Door Assy, Glove Compartment
55521C	Cover, Stereo Opening
55538A	Cover, Cooler Switch Hole
55539	Cover, Spare Switch Hole
55539B	Cover, Spare Switch Hole, NO.2
55539C	Cover, Spare Switch Hole
55539D	Cover, Spare Switch Hole
55545	Cover, Fuse Box Opening
55548A	Cover, Instrument Panel Hole
55553A	Pad, Glove Compartment Door
55560A	Lock Assy, Glove Compartment Door
55606	Cover Sub-assy, Instrument Panel Under, NO.1
55650	Register Assy, Instrument Panel, NO.1
55660	Register Assy, Instrument Panel, NO.2
55981	Garnish, Defroster Nozzle, NO.1
73960A	Airbag Assy, Instrument Panel Passenger W/O Door

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
