Toyota Camry

2002-03 → 2006-11 · chassis ACV30,31,MCV30 · catalogue 284370 · General

Discontinued model Data version 2007-04
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Panel & Back Window Glass

30 part groups · 2 illustrations

Illustrations

Figure 611961A 611961A 2002-03 → — Figure 611558B 611558B 2002-03 → —

Part groups

PNCDescription
56115B Stopper, Back Window Glass, NO.1
56116D Stopper, Back Window Glass, NO.2
63111 Panel, Roof
63118 Support, Roof Panel, RH
63119 Support, Roof Panel, LH
63132 Panel, Windshield Header, Inner
63133B Frame, Back Window
63137A Bracket, Dome Lamp, NO.1
63138 Bracket, Dome Lamp, NO.2
63141G Reinforcement, Roof Panel, NO.1
63143B Reinforcement, Roof Panel, NO.3
63144A Reinforcement, Roof Panel, NO.4
63201G Glass Sub-assy, Sliding Roof
63202H Rail Sub-assy, Slide Roof
63203F Housing Sub-assy, Sliding Roof
63206G Gear Sub-assy, Sliding Roof Drive
63209 Panel Sub-assy, Roof Wind Deflector
63214F Channel, Roof Drip, Rear
63217G Garnish, Sliding Roof Side, RH
63218G Garnish, Sliding Roof Side, LH
63223 Cable, Sliding Roof Drive, RH
63224 Cable, Sliding Roof Drive, LH
63236 Clamp, Sliding Roof OR Removable Roof Drain Hose
63241B Bracket, Sliding Roof Housing, NO.1
63249E Hose, Sliding Roof Drain
63249F Hose, Sliding Roof Drain
63251H Weatherstrip, Sliding Roof
64101 Panel Sub-assy, Upper Back
64165B Cover, Upper Back Panel Hole, NO.1
64811 Glass, Back Window
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
