Toyota Camry (AUSTRALIA)

2002-08 → 2006-06 · chassis ACV36,MCV36 · catalogue 285370 · General

Discontinued model Data version 2006-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Hood & Front Fender

24 part groups · 2 illustrations

Illustrations

Figure 531306E 531306E 2002-08 → — Figure 536814C 536814C 2002-08 → —

Part groups

PNCDescription
53301 Hood Sub-assy
53341B Insulator, Hood
53341C Clip(FOR HOOD INSULATOR)
53381 Seal, Hood TO Radiator Support
53381A Clip(FOR HOOD TO RADIATOR SUPPORT SEAL)
53388D Seal, Hood TO Front Fender, RH
53389B Seal, Hood TO Front Fender, LH
53801 Fender Sub-assy, Front RH
53802 Fender Sub-assy, Front LH
53845A Brace, Front Wheel Opening Apron, RH
53846A Brace, Front Wheel Opening Apron, LH
53866 Seal, Front Fender TO Cowl Side, RH
53867 Seal, Front Fender TO Cowl Side, LH
53875A Liner, Front Fender, RH
53875P Screw, NO.1
53875S Grommet, NO.1
53875T Grommet, NO.2
53875X Grommet, NO.3
53876A Liner, Front Fender, LH
53882B Seal, Front Fender, RH
53882F Seal, Front Fender
53883K Seal, Front Fender, LH
55738C Stopper, Hood, RH
55739E Stopper, Hood, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
