Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 32910F — Ring, O(FOR OIL COOLER) | ||||
| 90301-20012 |
Ring, O(FOR OIL COOLER)
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 90301-C0028 |
Ring, O(FOR OIL COOLER)
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 90301-20012 |
Ring, O(FOR OIL COOLER)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90301-20012 |
Ring, O(FOR OIL COOLER)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 33493A — Cooler, Transmission Oil(ATF WARMER) | ||||
| 33493-30020 |
Cooler, Transmission Oil(ATF WARMER)
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 33493-30050 |
Cooler, Transmission Oil(ATF WARMER)
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 33493-30050 |
Cooler, Transmission Oil(ATF WARMER)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 33493-30050 |
Cooler, Transmission Oil(ATF WARMER)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
