Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 42311N — Nut(FOR REAR AXLE SHAFT RH) | ||||
| 90177-26001 |
Nut(FOR REAR AXLE SHAFT RH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90177-26001 |
Nut(FOR REAR AXLE SHAFT RH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90177-26001 |
Nut(FOR REAR AXLE SHAFT RH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42311U — Bolt, Hub(FOR REAR AXLE RH) | ||||
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE RH)
2015-04 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90942-02070 |
Bolt, Hub(FOR REAR AXLE RH)
2015-01 → 2015-03
ended
|
GRS218 | — | |
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE RH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE RH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42312B — Nut(FOR REAR AXLE SHAFT LH) | ||||
| 90177-26001 |
Nut(FOR REAR AXLE SHAFT LH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90177-26001 |
Nut(FOR REAR AXLE SHAFT LH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90177-26001 |
Nut(FOR REAR AXLE SHAFT LH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42312E — Bolt, Hub(FOR REAR AXLE LH) | ||||
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE LH)
2015-04 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90942-02070 |
Bolt, Hub(FOR REAR AXLE LH)
2015-01 → 2015-03
ended
|
GRS218 | — | |
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE LH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE LH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42330 — Shaft Assy, Rear Drive, RH | ||||
| 42330-0N023 |
Shaft Assy, Rear Drive, RH
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 42330-0N030 |
Shaft Assy, Rear Drive, RH
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 42330-0N030 |
Shaft Assy, Rear Drive, RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42330-0N030 |
Shaft Assy, Rear Drive, RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42330G — Oil Seal, Rear Drive Shaft, RH | ||||
| 90311-43009 |
Oil Seal, Rear Drive Shaft, RH
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 90311-47018 |
Oil Seal, Rear Drive Shaft, RH
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 90311-47018 |
Oil Seal, Rear Drive Shaft, RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90311-47018 |
Oil Seal, Rear Drive Shaft, RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42340B — Shaft Assy, Rear Drive, LH | ||||
| 42340-0N023 |
Shaft Assy, Rear Drive, LH
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 42340-0N030 |
Shaft Assy, Rear Drive, LH
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 42340-0N030 |
Shaft Assy, Rear Drive, LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42340-0N030 |
Shaft Assy, Rear Drive, LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42340D — Oil Seal, Rear Drive Shaft, LH | ||||
| 90311-43009 |
Oil Seal, Rear Drive Shaft, LH
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 90311-47019 |
Oil Seal, Rear Drive Shaft, LH
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 90311-47019 |
Oil Seal, Rear Drive Shaft, LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90311-47019 |
Oil Seal, Rear Drive Shaft, LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42360L — Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT RH) | ||||
| 90521-34003 |
Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT RH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90521-34003 |
Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT RH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90521-34003 |
Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT RH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42360M — Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT LH) | ||||
| 90521-34003 |
Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT LH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90521-34003 |
Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT LH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90521-34003 |
Ring, Shaft Snap (FOR REAR DRIVE SHAFT INBOARD JOINT LH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42421E — Bolt (FOR REAR AXLE BEARING CASE RH) | ||||
| 90110-12009 note |
Bolt (FOR REAR AXLE BEARING CASE RH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90110-C0005 note |
Bolt (FOR REAR AXLE BEARING CASE RH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90110-12009 note |
Bolt (FOR REAR AXLE BEARING CASE RH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90110-12009 note |
Bolt (FOR REAR AXLE BEARING CASE RH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 90110-C0005 note |
Bolt (FOR REAR AXLE BEARING CASE RH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90110-C0005 note |
Bolt (FOR REAR AXLE BEARING CASE RH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42422A — Bolt (FOR REAR AXLE BEARING CASE LH) | ||||
| 90110-12009 note |
Bolt (FOR REAR AXLE BEARING CASE LH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90110-C0005 note |
Bolt (FOR REAR AXLE BEARING CASE LH)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90110-12009 note |
Bolt (FOR REAR AXLE BEARING CASE LH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90110-12009 note |
Bolt (FOR REAR AXLE BEARING CASE LH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 90110-C0005 note |
Bolt (FOR REAR AXLE BEARING CASE LH)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90110-C0005 note |
Bolt (FOR REAR AXLE BEARING CASE LH)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42431 — Disc, Rear | ||||
| 42431-0P010 |
Disc, Rear
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42431-0P010 |
Disc, Rear
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42431-0P010 |
Disc, Rear
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42450A — Hub & Bearing Assy, Rear Axle, RH | ||||
| 42410-0N010 |
Hub & Bearing Assy, Rear Axle, RH
2015-01 → 2015-03
ended
|
GRS218 | — | |
| 42410-0N011 |
Hub & Bearing Assy, Rear Axle, RH
2015-04 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42410-0N011 |
Hub & Bearing Assy, Rear Axle, RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42410-0N011 |
Hub & Bearing Assy, Rear Axle, RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42450B — Hub & Bearing Assy, Rear Axle, LH | ||||
| 42410-0N010 |
Hub & Bearing Assy, Rear Axle, LH
2015-01 → 2015-03
ended
|
GRS218 | — | |
| 42410-0N011 |
Hub & Bearing Assy, Rear Axle, LH
2015-04 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42410-0N011 |
Hub & Bearing Assy, Rear Axle, LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42410-0N011 |
Hub & Bearing Assy, Rear Axle, LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42451A — Deflector, Rear Wheel Bearing Dust, NO.1 RH | ||||
| 42451-30020 |
Deflector, Rear Wheel Bearing Dust, NO.1 RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42451-30020 |
Deflector, Rear Wheel Bearing Dust, NO.1 RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42451-30020 |
Deflector, Rear Wheel Bearing Dust, NO.1 RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42451B — Deflector, Rear Wheel Bearing Dust, NO.1 LH | ||||
| 42451-30020 |
Deflector, Rear Wheel Bearing Dust, NO.1 LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42451-30020 |
Deflector, Rear Wheel Bearing Dust, NO.1 LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42451-30020 |
Deflector, Rear Wheel Bearing Dust, NO.1 LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42491 — Plug, Shoe Adjusting Hole (FOR PARKING BRAKE) | ||||
| 47491-50010 |
Plug, Shoe Adjusting Hole (FOR PARKING BRAKE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47491-50010 |
Plug, Shoe Adjusting Hole (FOR PARKING BRAKE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47491-50010 |
Plug, Shoe Adjusting Hole (FOR PARKING BRAKE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
