Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04423 — Fitting Kit, Tire Pressure Monitor OR Balancer Valve | ||||
| 04423-0N010 |
Fitting Kit, Tire Pressure Monitor OR Balancer Valve
2016-03 → 2017-12
ended
|
ARS212,GRS218 Q,S,U | — | |
| 04423-33060 |
Fitting Kit, Tire Pressure Monitor OR Balancer Valve
2015-01 → 2016-03
ended
|
ARS212,GRS218 Q,S,U | — | |
| 04423-0N010 |
Fitting Kit, Tire Pressure Monitor OR Balancer Valve
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42601 — Wheel, Disc | ||||
| 42611-0N080 note |
Wheel, Disc
2015-01 → 2017-12
ended
|
ARS212,GRS218 U | — | |
| 4261A-0N010 note |
Wheel, Disc
2015-01 → 2017-12
ended
|
ARS212,GRS218 B,S | — | |
| 4261A-0N020 note |
Wheel, Disc
2015-01 → 2017-12
ended
|
ARS212,GRS218 B,S | — | |
| 4261A-0N030 note |
Wheel, Disc
2015-01 → 2017-12
ended
|
ARS212,GRS218 Q | — | |
| 4261A-0N030 note |
Wheel, Disc
2016-10 → 2017-12
ended
|
ARS212 S | — | |
| 4261A-0N040 note |
Wheel, Disc
2016-10 → 2017-12
ended
|
ARS212 S | — | |
| 4261A-0N040 note |
Wheel, Disc
2015-01 → 2017-12
ended
|
ARS212,GRS218 Q | — | |
| 42611-0N080 note |
Wheel, Disc
2017-12 → —
|
ARS212 P,Q,U | — | |
| 42611-0N130 note |
Wheel, Disc
2017-12 → —
|
ARS212 S | — | |
| 4261A-0N010 note |
Wheel, Disc
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 4261A-0N020 note |
Wheel, Disc
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42601A — Wheel, Disc (FOR SPARE) | ||||
| 42611-0N110 note |
Wheel, Disc (FOR SPARE)
2015-12 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42611-30F30 note |
Wheel, Disc (FOR SPARE)
2015-01 → 2016-12
ended
|
ARS212,GRS218 | — | |
| 42611-30F31 note |
Wheel, Disc (FOR SPARE)
2017-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 42611-0N110 note |
Wheel, Disc (FOR SPARE)
2017-12 → 2019-09
ended
|
ARS212 | — | |
| 42611-0N111 note |
Wheel, Disc (FOR SPARE)
2019-09 → —
|
ARS212 P,Q,S,U | — | |
| 42611-0N111 note |
Wheel, Disc (FOR SPARE)
2019-09 → 2019-10
ended
|
ARS212 B | — | |
| 42611-30F31 note |
Wheel, Disc (FOR SPARE)
2017-12 → 2019-08
ended
|
ARS212 | — | |
| 42611-30F32 note |
Wheel, Disc (FOR SPARE)
2019-09 → 2019-10
ended
|
ARS212 B | — | |
| 42611-30F32 note |
Wheel, Disc (FOR SPARE)
2019-09 → —
|
ARS212 P,Q,S,U | — | |
| 42601C — Nut, Hub (FOR AXLE) | ||||
| 90942-C1001 |
Nut, Hub (FOR AXLE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90942-C1001 |
Nut, Hub (FOR AXLE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90942-C1001 |
Nut, Hub (FOR AXLE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42607 — Valve Sub-assy, Tire Pressure Monitor | ||||
| 42607-0R020 |
Valve Sub-assy, Tire Pressure Monitor
2015-10 → 2017-12
ended
|
ARS212,GRS218 Q,S,U | — | |
| 42607-33040 |
Valve Sub-assy, Tire Pressure Monitor
2015-01 → 2015-09
ended
|
ARS212,GRS218 Q,S,U | — | |
| 42607-0R020 |
Valve Sub-assy, Tire Pressure Monitor
2017-12 → 2019-03
ended
|
ARS212 P,Q,S,U | — | |
| 42607-0R021 |
Valve Sub-assy, Tire Pressure Monitor
2019-04 → —
|
ARS212 P,Q,S,U | — | |
| 42611G — Valve (FOR TUBELESS TIRE) | ||||
| 90942-05028 |
Valve (FOR TUBELESS TIRE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 B | — | |
| 90942-05028 note |
Valve (FOR TUBELESS TIRE)
2015-01 → 2017-12
ended
|
GRS218 S | — | |
| 90942-05028 |
Valve (FOR TUBELESS TIRE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 42611J — Valve (FOR TUBELESS TIRE SPARE) | ||||
| 90942-05009 |
Valve (FOR TUBELESS TIRE SPARE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90942-05009 |
Valve (FOR TUBELESS TIRE SPARE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90942-05009 |
Valve (FOR TUBELESS TIRE SPARE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 42611U — Cap, Tire Valve | ||||
| 90942-05029 |
Cap, Tire Valve
2015-01 → 2017-12
ended
|
ARS212,GRS218 B | — | |
| 90942-05029 note |
Cap, Tire Valve
2015-01 → 2017-12
ended
|
GRS218 S | — | |
| 90942-05039 |
Cap, Tire Valve
2015-01 → 2015-09
ended
|
ARS212,GRS218 Q,S,U | — | |
| 90942-C5001 |
Cap, Tire Valve
2015-10 → 2017-12
ended
|
ARS212,GRS218 Q,S,U | — | |
| 90942-05029 |
Cap, Tire Valve
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90942-C5001 |
Cap, Tire Valve
2017-12 → —
|
ARS212 P,Q,S,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
