Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04465 — Pad Kit, Disc Brake, Front | ||||
| 04465-30330 note |
Pad Kit, Disc Brake, Front
2015-01 → 2017-05
ended
|
ARS212,GRS218 | — | |
| 04465-30480 note |
Pad Kit, Disc Brake, Front
2017-05 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 04465-30480 note |
Pad Kit, Disc Brake, Front
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 04465-30480 note |
Pad Kit, Disc Brake, Front
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 04479 — Cylinder Kit, Disc Brake, Front | ||||
| 04478-0N031 |
Cylinder Kit, Disc Brake, Front
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 04478-0N031 |
Cylinder Kit, Disc Brake, Front
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 04478-0N031 |
Cylinder Kit, Disc Brake, Front
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 04945 — Shim Kit, Anti Squeal, Front | ||||
| 04945-0P010 |
Shim Kit, Anti Squeal, Front
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 04945-0P010 |
Shim Kit, Anti Squeal, Front
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 04945-0P010 |
Shim Kit, Anti Squeal, Front
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 04947 — Fitting Kit, Disc Brake, Front | ||||
| 04947-0P010 |
Fitting Kit, Disc Brake, Front
2015-04 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 04947-30140 |
Fitting Kit, Disc Brake, Front
2015-01 → 2015-04
ended
|
GRS218 | — | |
| 04947-0P010 |
Fitting Kit, Disc Brake, Front
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 04947-0P010 |
Fitting Kit, Disc Brake, Front
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 31478B — Cap, Bleeder Plug(FOR FRONT DISC BRAKE) | ||||
| 31478-0N010 |
Cap, Bleeder Plug(FOR FRONT DISC BRAKE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 31478-0N010 |
Cap, Bleeder Plug(FOR FRONT DISC BRAKE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 31478-0N010 |
Cap, Bleeder Plug(FOR FRONT DISC BRAKE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47547B — Plug, Bleeder(FOR FRONT DISC BRAKE) | ||||
| 47547-27030 |
Plug, Bleeder(FOR FRONT DISC BRAKE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47547-20010 |
Plug, Bleeder(FOR FRONT DISC BRAKE)
2018-05 → —
|
ARS212 P,Q,S,U | — | |
| 47547-20010 |
Plug, Bleeder(FOR FRONT DISC BRAKE)
2018-05 → 2019-10
ended
|
ARS212 B | — | |
| 47547-27030 |
Plug, Bleeder(FOR FRONT DISC BRAKE)
2017-12 → 2018-05
ended
|
ARS212 | — | |
| 47710A — Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER) | ||||
| 90119-12415 note |
Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90119-C0372 note |
Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90119-12415 note |
Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90119-12415 note |
Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 90119-C0372 note |
Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90119-C0372 note |
Bolt, Hexagon(FOR FRONT DISC BRAKE CALIPER)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47715A — Pin, Front Disc Brake Cylinder Slide | ||||
| 47714-0P010 |
Pin, Front Disc Brake Cylinder Slide
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47714-0P010 |
Pin, Front Disc Brake Cylinder Slide
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47714-0P010 |
Pin, Front Disc Brake Cylinder Slide
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47715B — Bolt(FOR FRONT DISC BRAKE CYLINDER SLIDE) | ||||
| 90016-AA608 |
Bolt(FOR FRONT DISC BRAKE CYLINDER SLIDE)
2015-04 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90105-08164 |
Bolt(FOR FRONT DISC BRAKE CYLINDER SLIDE)
2015-01 → 2015-04
ended
|
GRS218 | — | |
| 90016-AA608 |
Bolt(FOR FRONT DISC BRAKE CYLINDER SLIDE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90016-AA608 |
Bolt(FOR FRONT DISC BRAKE CYLINDER SLIDE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47715D — Pin, Front Disc Brake Cylinder Slide, NO.2 | ||||
| 47715-0P010 |
Pin, Front Disc Brake Cylinder Slide, NO.2
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47715-0P010 |
Pin, Front Disc Brake Cylinder Slide, NO.2
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47715-0P010 |
Pin, Front Disc Brake Cylinder Slide, NO.2
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47721 — Mounting, Front Disc Brake Cylinder, RH | ||||
| 47721-0P011 |
Mounting, Front Disc Brake Cylinder, RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47721-0P011 |
Mounting, Front Disc Brake Cylinder, RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47721-0P011 |
Mounting, Front Disc Brake Cylinder, RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47722 — Mounting, Front Disc Brake Cylinder, LH | ||||
| 47721-0P011 |
Mounting, Front Disc Brake Cylinder, LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47721-0P011 |
Mounting, Front Disc Brake Cylinder, LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47721-0P011 |
Mounting, Front Disc Brake Cylinder, LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47730 — Cylinder Assy, Front Disc Brake, RH | ||||
| 47730-0P011 |
Cylinder Assy, Front Disc Brake, RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47730-0P011 |
Cylinder Assy, Front Disc Brake, RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47730-0P011 |
Cylinder Assy, Front Disc Brake, RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47731 — Piston, Front Disc Brake | ||||
| 47731-33070 |
Piston, Front Disc Brake
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47731-30570 |
Piston, Front Disc Brake
2020-02 → 2020-04
ended
|
ARS212 | — | |
| 47731-33070 |
Piston, Front Disc Brake
2017-12 → 2020-02
ended
|
ARS212 | — | |
| 47731A — Ring, Set(FOR FRONT DISC BRAKE PISTON) | ||||
| 90520-86005 |
Ring, Set(FOR FRONT DISC BRAKE PISTON)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90520-86005 |
Ring, Set(FOR FRONT DISC BRAKE PISTON)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90520-86005 |
Ring, Set(FOR FRONT DISC BRAKE PISTON)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47750 — Cylinder Assy, Disc Brake, LH | ||||
| 47750-0P011 |
Cylinder Assy, Disc Brake, LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47750-0P011 |
Cylinder Assy, Disc Brake, LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47750-0P011 |
Cylinder Assy, Disc Brake, LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47769 — Bush, Cylinder Slide, NO.1(FOR FRONT DISC BRAKE) | ||||
| 47769-0P010 |
Bush, Cylinder Slide, NO.1(FOR FRONT DISC BRAKE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47769-0P010 |
Bush, Cylinder Slide, NO.1(FOR FRONT DISC BRAKE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47769-0P010 |
Bush, Cylinder Slide, NO.1(FOR FRONT DISC BRAKE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47771 — Plate, Pad Wear Indicator, NO.1 | ||||
| 47771-30090 |
Plate, Pad Wear Indicator, NO.1
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47771-30090 |
Plate, Pad Wear Indicator, NO.1
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47771-30090 |
Plate, Pad Wear Indicator, NO.1
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47775 — Boot, Bush Dust(FOR FRONT DISC BRAKE) | ||||
| 47775-50010 |
Boot, Bush Dust(FOR FRONT DISC BRAKE)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47775-50010 |
Boot, Bush Dust(FOR FRONT DISC BRAKE)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47775-50010 |
Boot, Bush Dust(FOR FRONT DISC BRAKE)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47781 — Cover, Disc Brake Dust, Front RH | ||||
| 47781-0N010 |
Cover, Disc Brake Dust, Front RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47781-0N010 |
Cover, Disc Brake Dust, Front RH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47781-0N010 |
Cover, Disc Brake Dust, Front RH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47782 — Cover, Disc Brake Dust, Front LH | ||||
| 47782-0N010 |
Cover, Disc Brake Dust, Front LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47782-0N010 |
Cover, Disc Brake Dust, Front LH
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47782-0N010 |
Cover, Disc Brake Dust, Front LH
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 47795 — Plate, Front Disc Brake Caliper, NO.1 | ||||
| 47795-30520 |
Plate, Front Disc Brake Caliper, NO.1
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 47795-30520 |
Plate, Front Disc Brake Caliper, NO.1
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 47795-30520 |
Plate, Front Disc Brake Caliper, NO.1
2017-12 → —
|
ARS212 P,Q,S,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
