Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44510 — Actuator Assy, Brake | ||||
| 44050-0N010 |
Actuator Assy, Brake
2015-01 → 2017-12
ended
|
GRS218 | — | |
| 44050-0N020 note |
Actuator Assy, Brake
2015-01 → 2017-12
ended
|
GRS218 U | — | |
| 44050-0N030 |
Actuator Assy, Brake
2015-08 → 2017-12
ended
|
ARS212 | — | |
| 44050-0N040 note |
Actuator Assy, Brake
2015-08 → 2017-12
ended
|
ARS212 U | — | |
| 44050-0N050 |
Actuator Assy, Brake
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 44050-0N050 |
Actuator Assy, Brake
2017-12 → —
|
ARS212 P,Q,S | — | |
| 44050-0N060 |
Actuator Assy, Brake
2017-12 → —
|
ARS212 U | — | |
| 44546A — Cushion, Brake Actuator Bolt | ||||
| 44546-12120 |
Cushion, Brake Actuator Bolt
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 44546-12110 |
Cushion, Brake Actuator Bolt
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 44546-12110 |
Cushion, Brake Actuator Bolt
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 44590 — Bracket Assy, Brake Actuator | ||||
| 44590-0N030 |
Bracket Assy, Brake Actuator
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 44590-0N040 |
Bracket Assy, Brake Actuator
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 44590-0N040 |
Bracket Assy, Brake Actuator
2017-12 → —
|
ARS212 P,Q,S,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
