Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 63395E — Clip(FOR MAP LAMP) | ||||
| 90467-10167 |
Clip(FOR MAP LAMP)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90467-10167 |
Clip(FOR MAP LAMP)
2017-12 → 2019-10
ended
|
ARS212 B | — | |
| 90467-10167 |
Clip(FOR MAP LAMP)
2017-12 → —
|
ARS212 P,Q,S,U | — | |
| 81260A — Lamp Assy, Map | ||||
| 81260-0N180-A0 note |
Lamp Assy, Map
2015-01 → 2017-12
ended
|
ARS212,GRS218 B | — | |
| 81260-0N190-A0 note |
Lamp Assy, Map
2015-01 → 2017-12
ended
|
ARS212,GRS218 U | — | |
| 81260-0N190-B0 note |
Lamp Assy, Map
2015-01 → 2017-12
ended
|
ARS212,GRS218 U | — | |
| 81260-0N200-A0 note |
Lamp Assy, Map
2015-01 → 2017-12
ended
|
ARS212,GRS218 Q,S | — | |
| 81260-0N200-B0 note |
Lamp Assy, Map
2015-01 → 2017-12
ended
|
ARS212 Q;GRS218 Q,S | — | |
| 81260-0N200-B0 note |
Lamp Assy, Map
2015-08 → 2017-12
ended
|
ARS212 S | — | |
| 81260-0N210-A0 note |
Lamp Assy, Map
2017-12 → 2019-05
ended
|
ARS212 B | — | |
| 81260-0N211-A0 note |
Lamp Assy, Map
2019-06 → 2019-10
ended
|
ARS212 B | — | |
| 81260-0N220-A0 note |
Lamp Assy, Map
2017-12 → 2019-05
ended
|
ARS212 P,Q,S | — | |
| 81260-0N220-B0 note |
Lamp Assy, Map
2017-12 → 2019-05
ended
|
ARS212 Q,S | — | |
| 81260-0N220-B0 note |
Lamp Assy, Map
2017-12 → 2019-05
ended
|
ARS212 P | — | |
| 81260-0N221-A0 note |
Lamp Assy, Map
2019-06 → —
|
ARS212 Q,S | — | |
| 81260-0N221-B0 note |
Lamp Assy, Map
2019-06 → —
|
ARS212 P | — | |
| 81260-0N221-B0 note |
Lamp Assy, Map
2019-06 → —
|
ARS212 Q,S | — | |
| 81260-0N230-A0 note |
Lamp Assy, Map
2017-12 → 2019-05
ended
|
ARS212 U | — | |
| 81260-0N230-B0 note |
Lamp Assy, Map
2017-12 → 2019-05
ended
|
ARS212 U | — | |
| 81260-0N231-A0 note |
Lamp Assy, Map
2019-06 → —
|
ARS212 U | — | |
| 81260-0N231-B0 note |
Lamp Assy, Map
2019-06 → —
|
ARS212 U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
