Toyota Crown (CHINA)
2015-01 → 2020-04 · chassis ARS212,GRS218 · catalogue 330230 · General
Supported model
Data version 2020-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 85110 — Motor Assy, Windshield Wiper | ||||
| 85110-0N030 |
Motor Assy, Windshield Wiper
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85110-0N030 |
Motor Assy, Windshield Wiper
2017-12 → —
|
ARS212 | — | |
| 85160 — Link Assy, Windshield Wiper | ||||
| 85150-0N030 |
Link Assy, Windshield Wiper
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85150-0N030 |
Link Assy, Windshield Wiper
2017-12 → —
|
ARS212 | — | |
| 85178 — Nut (FOR FRONT WIPER ARM SETTING) | ||||
| 90176-10005 |
Nut (FOR FRONT WIPER ARM SETTING)
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 90176-10005 |
Nut (FOR FRONT WIPER ARM SETTING)
2017-12 → —
|
ARS212 | — | |
| 85211B — Arm, Front Wiper, RH | ||||
| 85211-0N020 |
Arm, Front Wiper, RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85211-0N020 |
Arm, Front Wiper, RH
2017-12 → —
|
ARS212 | — | |
| 85212A — Blade, FR Wiper, RH | ||||
| 85212-0N020 |
Blade, FR Wiper, RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85212-0N020 |
Blade, FR Wiper, RH
2017-12 → —
|
ARS212 | — | |
| 85214A — Rubber, Wiper, RH | ||||
| 85214-33180 |
Rubber, Wiper, RH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85214-33180 |
Rubber, Wiper, RH
2017-12 → —
|
ARS212 | — | |
| 85214B — Rubber, Wiper, LH | ||||
| 85214-30380 |
Rubber, Wiper, LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85214-30380 |
Rubber, Wiper, LH
2017-12 → —
|
ARS212 | — | |
| 85221B — Arm, Front Wiper, LH | ||||
| 85221-0N020 |
Arm, Front Wiper, LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85221-0N020 |
Arm, Front Wiper, LH
2017-12 → —
|
ARS212 | — | |
| 85222A — Blade, FR Wiper, LH | ||||
| 85222-0N020 |
Blade, FR Wiper, LH
2015-01 → 2017-12
ended
|
ARS212,GRS218 | — | |
| 85222-0N020 |
Blade, FR Wiper, LH
2017-12 → —
|
ARS212 | — | |
| 89941 — Sensor, Rain | ||||
| 89941-52010 |
Sensor, Rain
2015-01 → 2017-12
ended
|
ARS212,GRS218 Q,U | — | |
| 89941-52010 |
Sensor, Rain
2017-12 → —
|
ARS212 P,Q,U | — | |
| 89943 — Cover, Rain Sensor | ||||
| 89943-33050 |
Cover, Rain Sensor
2015-01 → 2017-12
ended
|
ARS212,GRS218 Q,U | — | |
| 89943-33050 |
Cover, Rain Sensor
2017-12 → —
|
ARS212 P,Q,U | — | |
| 89944 — Tape, Rain Sensor | ||||
| 89944-42010 |
Tape, Rain Sensor
2015-01 → 2017-12
ended
|
ARS212,GRS218 Q,U | — | |
| 89944-42010 |
Tape, Rain Sensor
2017-12 → —
|
ARS212 P,Q,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
