Toyota Crown
1987-09 → 1991-10 · chassis YS132,MS13#,GS131,LS130 · catalogue 331260 · General
Discontinued model
Data version 1992-06
Front Seat & Seat Track
142 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 71071P | Cover, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073P | Cover, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074P | Cover, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71170A | Holder Assy, Front Seat Armrest, RH |
| 71328B | Washer, Front Seatback Pocket Setting, RH |
| 71328C | Washer, Front Seatback Pocket Setting, LH |
| 71377A | Bracket, Front Seat, RH |
| 71378 | Bracket, Front Seat, LH |
| 71410P | Cushion Assy, Front Seat(FOR SEMI-SEPARATE TYPE) |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430P | Back Assy, Front Seat, RH(FOR SEMI-SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440P | Back Assy, Front Seat, LH(FOR SEMI-SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71511P | Pad, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71513B | Pad, Front Seat Cushion, B |
| 71515 | Pad, Front Seat Cushion, D |
| 71516 | Pad, Front Seat Cushion, E |
| 71521 | Pad, Front Seat Cushion Silencer, A |
| 71522A | Pad, Front Seat Cushion Silencer, B |
| 71523A | Pad, Front Seat Cushion Silencer, C |
| 71524 | Pad, Front Seat Cushion Silencer, D |
| 71531 | Pad, Front Seat Cushion Corner, A |
| 71532 | Pad, Front Seat Cushion Corner, B |
| 71551P | Pad, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552P | Pad, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71554 | Pad, Front Seatback, C |
| 71563A | Pad, Front Seatback Side, RH |
| 71564A | Pad, Front Seatback Side, LH |
| 71565A | Pad, Front Seatback, Inside RH |
| 71566 | Pad, Front Seatback, Inside LH |
| 71567 | Pad, Front Seatback Safety |
| 71571 | Pad, Front Seatback Silencer, A |
| 71572 | Pad, Front Seatback Silencer, B |
| 71572A | Pad, Front Seatback Silencer, B |
| 71573 | Pad, Front Seatback Silencer, C |
| 71584B | Pad, Front Seatback Corner, D |
| 71587 | Protector, Front Seatback Edge |
| 71587B | Protector, Front Seatback Edge |
| 71610P | Spring Assy, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71610S | Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71620S | Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71630P | Spring Assy, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71630S | Spring Assy, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71640P | Spring Assy, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71640S | Spring Assy, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71705 | Board Sub-assy, Front Seatback, RH |
| 71706 | Board Sub-assy, Front Seatback, LH |
| 71708B | Strap Sub-assy, Seat Cover |
| 71711 | Leather, For Seat, A RH |
| 71712 | Leather, For Seat, B RH |
| 71731 | Fastener Sub-assy, Seat Cover, A (FOR FRONT SEAT) |
| 71732 | Fastener, Seat Cover, B (FOR FRONT SEAT) |
| 71733 | Retainer, Seat Cover Fastener, A (FOR FRONT SEAT) |
| 71801C | Board Sub-assy, Front Seat Arnrest Hole |
| 71811C | Cover, Reclining Adjuster, RH |
| 71812C | Cover, Reclining Adjuster, LH |
| 71831A | Cover, Front Seat Hinge |
| 71831D | Cover, Front Seat Hinge, RH |
| 71832D | Cover, Front Seat Hinge, LH |
| 71848A | Cap, Seat Adjuster Cover, RH |
| 71849 | Cap, Seat Adjuster Cover, LH |
| 71861 | Shield, Front Seat Cushion, Inner RH |
| 71862 | Shield, Front Seat Cushion, Inner LH |
| 71867A | Shield, Front Seat Cushion, Inner NO.1 RH |
| 71868A | Shield, Front Seat Cushion, Inner NO.1 LH |
| 71873 | Shield, Front Seat Cushion, Lower RH |
| 71874 | Shield, Front Seat Cushion, Lower LH |
| 71875A | Cover, Reclining Adjuster Inside, RH |
| 71876 | Cover, Reclining Adjuster Inside, LH |
| 71893A | Shield, Power Adjuster, Front RH |
| 71894A | Shield, Power Adjuster, Front LH |
| 71910A | Headrest Assy, Front Seat |
| 71931 | Support, Front Seat Headrest |
| 71937 | Handle, Front Seat Headrest Regulator |
| 72043B | Lever Sub-assy, Seat Lifter, RH |
| 72044B | Lever Sub-assy, Seat Lifter, LH |
| 72110 | Regulator Assy, Power Seat, RH |
| 72110A | Track Assy, Front Seat, Outer RH |
| 72120 | Track Assy, Front Seat, Outer LH |
| 72120A | Regulator Assy, Power Seat, LH |
| 72123A | Cover, Seat Track Bracket, Outer Front RH |
| 72124 | Cover, Seat Track Bracket, Outer Front LH |
| 72127A | Cover, Seat Track Bracket, Inner Front RH |
| 72128A | Cover, Seat Track Bracket, Inner Front LH |
| 72130A | Track Assy, Front Seat, Inner RH |
| 72137B | Cover, Seat Track, RH |
| 72138B | Cover, Seat Track, LH |
| 72140A | Track Assy, Front Seat,Inner LH |
| 72157A | Cover, Seat Track Bracket, Inner RH |
| 72158 | Cover, Seat Track Bracket, Inner LH |
| 72205A | Housing Sub-assy, Power Seat, NO.1 |
| 72205E | Housing Sub-assy, Power Seat, NO.1 |
| 72206 | Housing Sub-assy, Power Seat, NO.2 |
| 72206C | Housing Sub-assy, Power Seat, NO.2 |
| 72211 | Handle, Seat Track Adjusting |
| 72213 | Knob, Seat Track Adjusting Handle |
| 72213B | Knob, Seat Track Adjusting Handle, RH |
| 72213C | Knob, Seat Track Adjusting Handle, LH |
| 72301A | Wire Sub-assy, Seat Track Equalizing, RH |
| 72301D | Wire Sub-assy, Seat Track Equalizing, LH |
| 72310A | Adjuster Assy, Front Seat Vertical |
| 72320A | Adjuster Assy, Front Seat Vertical, LH |
| 72405 | Housing Sub-assy, Front Seat Vertical |
| 72405A | Housing Sub-assy, Front Seat Vertical |
| 72459 | Cap, Vertical Seat Adjuster Knob |
| 72459A | Cap, Vertical Seat Adjuster Knob |
| 72480 | Adjuster Assy, Front Seat Vertical, NO.2 RH |
| 72490 | Adjuster Assy, Front Seat Vertical, NO.2 LH |
| 72501D | Pipe Sub-assy, Reclining Connecting, RH |
| 72501E | Pipe Sub-assy, Reclining Connecting, LH |
| 72510A | Spring, Tension, NO.1(FOR RECLINING SEAT ADJUSTER) |
| 72510D | Adjuster Assy, Reclining Seat, Outer RH |
| 72520 | Adjuster Assy, Reclining Seatback, LH |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526 | Handle, Reclining Adjuster Release, LH |
| 72530A | Adjuster Assy, Reclining Seat, Inner RH |
| 72540A | Adjuster Assy, Reclining Seat, Inner LH |
| 72750D | Adjuster Assy, Lumbar Support, RH |
| 72760D | Adjuster Assy, Lumbar Support, LH |
| 72791 | Lever, Lumbar Support |
| 72791A | Ring, Shaft Snap(FOR LUMBER SUPPORT LEVER) |
| 72805 | Link Sub-assy, Front Seat Center Armrest, RH |
| 72806 | Link Sub-assy, Front Seat Center Armrest, LH |
| 72810C | Armrest Assy, Front Seat, Center |
| 72877 | Cover, Seat Armrest, RH |
| 72878 | Cover, Seat Armrest, LH |
| 74617D | Plug, Assist Grip |
| 74620A | Grip Assy, Assist, Rear |
| 74671C | Support, Assist Grip |
| 74841A | Panel, Front Seatback Control |
| 74843B | Ornament, Front Seatback Control Panel |
| 74849A | Retainer, Front Seatback Control Panel Set |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
