Toyota Crown

1991-10 → 2001-04 · chassis GS131,JZS133,LS130,YS132 · catalogue 331270 · General

Discontinued model Data version 2002-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

21 part groups · 2 illustrations

Illustrations

Figure 746063 746063 1991-10 → — Figure MBV891B MBV891B 1991-10 → —

Part groups

PNCDescription
11277A Plate, Engine Specification, NO.2
11278B Label, Engine Emission Compliance Information
11284A Plate, Engine Bolt Information
11286B Plate, Engine Specification
11293D Label, Engine Caution
11296C Label, Engine Service Information
11296D Label, Engine Service Information
13564 Label, Timing Belt Replacement Information
17700R Label, Air Cleaner Information
17791A Label, Maintenance Information
23923A Label, Fuel Sedimenter Notice
47995 Label, Brake Tube Caution
74529 Plate, Child Proof OR Child Protector Lock Caution
74541 Plate, Tire Pressure Caution
74541E Plate, Compact Spare Tire Caution
74559A Plate, Fuel Caution
74562 Plate, Emission Control System Information
74563 Plate, Emission Control Device Identification
74571 Plate, Brake Fluid Caution
74579A Label, Unleaded Fuel Information
75341C Plate, Hood Name
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
