Toyota Crown
1991-10 → 2001-04 · chassis GS131,JZS133,LS130,YS132 · catalogue 331270 · General
Discontinued model
Data version 2002-01
Cruise Control (AUTO DRIVE)
12 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 83731 | Cable, Cruise Control |
| 84630 | Switch Assy, Cruise Control Main |
| 84639 | Label, Cruise Control Switch Infomation |
| 88002 | Cruise Control(AUTO DRIVE) Set |
| 88200B | Hose, Cruise Control Vacuum |
| 88200D | Actuator Assy, Cruise Control |
| 88212A | Cover, Cruise Control Actuator |
| 88240 | Computer Assy, Cruise Control |
| 88241 | Computer, Speed Control |
| 88280C | Switch Assy, Clutch |
| 88291 | Bracket, Cruise Control(AUTO DRIVE), NO.1 |
| 89279E | Cover, Cruise Control(AUTO DRIVE) Computer |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
