Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11011 — Washer Set, Crankshaft Thrust | ||||
| 11011-31060 note |
Washer Set, Crankshaft Thrust
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11711 — Bearing, Crankshaft | ||||
| 11071-31031-01 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11071-31031-02 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11071-31031-03 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11071-31031-04 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11071-31031-05 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11701-31061-01 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11701-31061-02 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11701-31061-03 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11701-31061-04 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 11701-31061-05 note |
Bearing, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13011 — Ring Set, Piston | ||||
| 13011-31180 note |
Ring Set, Piston
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13041 — Bearing, Connecting Rod | ||||
| 13041-31051-01 note |
Bearing, Connecting Rod
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13041-31051-02 note |
Bearing, Connecting Rod
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13041-31051-03 note |
Bearing, Connecting Rod
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13041-31051-04 note |
Bearing, Connecting Rod
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13101 — Piston Sub-assy, W/Pin | ||||
| 13101-31080-A0 note |
Piston Sub-assy, W/Pin
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13101-31080-B0 note |
Piston Sub-assy, W/Pin
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13101-31080-C0 note |
Piston Sub-assy, W/Pin
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13101A — Ring, Hole Snap(FOR PISTON PIN) | ||||
| 90520-22025 |
Ring, Hole Snap(FOR PISTON PIN)
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13201 — Rod Sub-assy, Connecting | ||||
| 13201-39066-A0 note |
Rod Sub-assy, Connecting
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13201-39066-B0 note |
Rod Sub-assy, Connecting
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13201-39066-C0 note |
Rod Sub-assy, Connecting
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13201A — Bush(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73144 |
Bush(FOR CONNECTING ROD SMALL END)
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13265 — Bolt, Connecting Rod | ||||
| 13265-28010 |
Bolt, Connecting Rod
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13301 — Piston Sub-assy, W/Pin, LH | ||||
| 13301-31050-A0 note |
Piston Sub-assy, W/Pin, LH
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13301-31050-B0 note |
Piston Sub-assy, W/Pin, LH
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13301-31050-C0 note |
Piston Sub-assy, W/Pin, LH
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13411 — Crankshaft | ||||
| 13401-31020 |
Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13471 — Pulley, Crankshaft | ||||
| 13470-31021 |
Pulley, Crankshaft
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13471C — Bolt(FOR CRANKSHAFT PULLEY SET) | ||||
| 90119-16004 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13521 — Gear OR Sprocket, Crankshaft Timing | ||||
| 13521-31041 |
Gear OR Sprocket, Crankshaft Timing
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13521A — Key(FOR CRANKSHAFT TIMING GEAR) | ||||
| 95161-30516 |
Key(FOR CRANKSHAFT TIMING GEAR)
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13581 — Shaft, Idle Gear, NO.1 | ||||
| 13581-31030 |
Shaft, Idle Gear, NO.1
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
| 13582 — Shaft, Idle Gear, NO.2 | ||||
| 13582-31031 |
Shaft, Idle Gear, NO.2
2010-09 → 2012-12
ended
|
3GRFE GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
