Toyota Crown
2010-09 → 2012-12 · chassis GRS202 · catalogue 3312C0 · General
Supported model
Data version 2013-01
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 30250 — Converter Assy, Torque, Rebuilt | ||||
| 30250-30390 |
Converter Assy, Torque, Rebuilt
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 32000 — Converter Assy, Torque | ||||
| 32000-30390 |
Converter Assy, Torque
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 32101 — Gear Sub-assy, Drive Plate & Ring | ||||
| 32101-30080 |
Gear Sub-assy, Drive Plate & Ring
2010-09 → 2011-05
ended
|
GRS202 | — | |
| 32101-30081 |
Gear Sub-assy, Drive Plate & Ring
2011-06 → 2012-12
ended
|
GRS202 | — | |
| 32101A — Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING) | ||||
| 90105-09005 note |
Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 90105-09006 note |
Bolt(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 32101C — Bolt, Hexagon(FOR DRIVE PLATE SETTING) | ||||
| 90105-10048 note |
Bolt, Hexagon(FOR DRIVE PLATE SETTING)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 32116 — Spacer, Drive Plate, Front | ||||
| 32116-32020 |
Spacer, Drive Plate, Front
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 32117 — Spacer, Drive Plate, Rear | ||||
| 32117-30030 |
Spacer, Drive Plate, Rear
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35301 — Body Sub-assy, Front Oil Pump | ||||
| 35301-22030 |
Body Sub-assy, Front Oil Pump
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35301A — Seal, Oil (FOR FRONT OIL PUMP) | ||||
| 90311-38083 |
Seal, Oil (FOR FRONT OIL PUMP)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35301B — Ring, O (FOR FRONT OIL PUMP BODY) | ||||
| 90301-99093 note |
Ring, O (FOR FRONT OIL PUMP BODY)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 90301-99153 note |
Ring, O (FOR FRONT OIL PUMP BODY)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35301F — Bolt (FOR FRONT OIL PUMP SETTING) | ||||
| 90105-08451 note |
Bolt (FOR FRONT OIL PUMP SETTING)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35301G — Bearing,Needle Roller | ||||
| 90364-33013 |
Bearing,Needle Roller
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35307F — Bolt (FOR STATOR SHAFT) | ||||
| 90148-60079 |
Bolt (FOR STATOR SHAFT)
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321 — Gear, Front Oil Pump Drive | ||||
| 35321-22120 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321-22130 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321-22140 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321-22150 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321-22160 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321-22170 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35321-22180 note |
Gear, Front Oil Pump Drive
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322 — Gear, Front Oil Pump Driven | ||||
| 35322-22120 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322-22130 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322-22140 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322-22150 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322-22160 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322-22170 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35322-22180 note |
Gear, Front Oil Pump Driven
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35370 — Shaft Assy, Stator | ||||
| 35370-22070 |
Shaft Assy, Stator
2010-09 → 2012-12
ended
|
GRS202 | — | |
| 35617 — Ring, Clutch Drum Oil Seal | ||||
| 35617-50030 |
Ring, Clutch Drum Oil Seal
2010-09 → 2012-12
ended
|
GRS202 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
